Specifications
usd for roofing sheet insulated roof sheetsbuilding material construction
Material to be suitable for color coating
1.short delivery
2. high-quality
3. low prices
4.quality advantage
The galvanized steel is to prevent the steel plate surface from corrosion and
prolong its service life, on the steel plate surface coated with a layer of metal zinc .
The galvanized steel has excellent plasticity, welding, impact resistance,
corrosion resistance and good coating.
goods |
Hot dip galvanized steel coil and sheet |
Technical Standard: |
JIS 3302 / ASTM A653 / EN10143/EN10327 |
Grade |
DX51D / DX52D/ DX53D/ S250,280,320GD |
Width |
914/1000/1200/1219/1220/1250mm |
Thickness |
0.17-1.6mm (0.20-0.80mm is the most advantage thickness) |
Type of coating: |
galvanized |
Zinc coating |
Z40-100g/m2 |
Surface treatment |
chromed / skin pass/ oiled /un oiled /slightly oiled/ dry |
Surface structure: |
zero spangle / minimized spangle / regular spangle/ |
ID coil |
508mm or 610mm |
Coil weight |
2-8 MT per coil |
Package: |
Properly packed for ocean freight exportation in 20''containers |
Price terms |
FOB,CFR,CIF |
Payment terms |
1. 100%TT 2.30%TT+70%TT before shipment 3.30%TT+70% against B/L copy 4.30%TT+70%L/C at sight 5.100%L/C at sight 6.escrow service on alibaba |
delivery time |
about 20 days after receipt format contract |
The industrial use
The application field |
example illustration |
The electrical appliance industry |
Air conditioner,Computer chassis, Plate for refrigerator,Outer shell of washing machine,kitchen fittings, The freezing chamber device |
The building industry |
housetop,Lateral wall,doors and windows, gutter,Shutter doors and windows,Wall frame , Ceiling joist,ventiduct |
The agricultural and pastoral |
Granary,silo,animal house,trough,flume,Greenhouse trellis,Baking equipment; |
The transport |
railroad:The roof of the train,The internal frame of train,The road sign,The inner walls of the train; |
The equipment and structure |
radiator,cold roll-formed ,Pedals and rack |
The material and mechanical properties
Material |
Tensile test |
||||||
|
Rel (MPa) |
Rm (MPa) |
Elongation |
|||||
1.8~<2.0 |
2.0~<2.5 |
2.5~<3.2 |
3.2~<4.0 |
≥4.0 |
|||
SPHC |
≥270 |
≥29 |
≥30 |
≥31 |
≥32 |
≥32 |
|
SPHD |
≥270 |
≥32 |
≥33 |
≥35 |
≥37 |
≥39 |
|
SPHE |
≥270 |
≥33 |
≥35 |
≥37 |
≥39 |
≥41 |
|
SS330 |
≥205 |
330~430 |
≥26 |
||||
SS400 |
≥245 |
400~510 |
≥24 |
||||
SAPH370 |
≥370 |
≥255 |
≥32 |
||||
Note:1.Tensile tests specified in column in the table for the value of longitudinal specimens.
2. Tensile test specimens by LO=50mm b=25mm,is P14 specimen in GB/T228.
