100 Meter IR Distance Outdoor Zoom High Speed 720p Night Vision Megapixel Waterproof High Definition Industry Security Camera

100 Meter IR Distance Outdoor Zoom High Speed 720p Night Vision Megapixel Waterproof High Definition Industry Security Camera thumbnail-1
100 Meter IR Distance Outdoor Zoom High Speed 720p Night Vision Megapixel Waterproof High Definition Industry Security Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
1King
Model Number:
HDIPC308
Contact Supplier Request Quote Chat Now
Shenzhen Oneking Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name 1King
Model Number HDIPC308
Type Analog Camera
Style Dome Camera
Sensor CCD
Technology Infrared
Special Features Waterproof / Weatherproof

Specifications

1. security camera.
2. Waterproof.
3. 1.3/2.0 mega pixels optional.
4.18X optical zoom.
5.150M Long IR distance.

100 meter IR distance Outdoor zoom high speed 720p night vision megapixel waterproof high definition  industry security camera



1. Standard H.264 Video Compression

2. 1.3/2.0 megapixel  HD 1080p IP Camera

  18x  Optical Zoom( camera module Optional)

3. 150m IR Distance

    2 Groups IR LED array

4. Vandual-Proof Housing use for Outdoor IP67

    RS485, PELCO-P, PELCO-D

5. 128 preset positions, 8 cruise group

6. Support RTSP, VLC(PS/TS) Streaming protocol

7. 360 degree Pan & 90 degree Tilt

    1-180°/s(1-64 grade available) Pan & Tilt Speed

8. Multi-Level User access with password protection

9. Support WEB-browser, Remote configure/update, replay, record

10. Alarm I/O Support motion detection, date, time, event trigger



Model No.
HDIPC308F
Image Sensor
1/2.8" Type Exmor CMOS
Effective Pixels
1.3/2.0 megapixels optional
Min. Illuminationt
0.5Lux at F1.6
IR Led
changeable IR lights
IR Distance
150m
Day/Night
ICR with removeable IR filter
Exposure Control
Auto
Electronic Shutter
1/1sec to 1/10000sec
Gain Control
Auto(High/Middle/Low)
White Balance
Auto/Close
S/N Ratio
50DB
focal length
f=4.7-90mm,F1.6-F3.5
Zoom
22 optical x 12 digital zoom
HOV
Horizontal: 55.4°
Video Compression
H.264
Video Compressed Code Rate
1-16Mbps,CBR/VBR(adjustable)
Max Image Resolution
1920*1080
Frame Rate
30fps(1920*1080),(1019*768),(800*600),(352*288)
Dual-stream
30fps(1920*1080),(352*288),(1019*768),(704*576),(800*600),(704*576)
Audio Compression
G.726G.722G.711
Audio Compression Code Rate
64Kbps
Network Interface
RJ45 X 1,10/100M self-adaption Ethernet port
Network Protocols
TCP/IP,HTTP,DHCP,DNS,DDNS,FTP,NTP,PPPOE,RTSP,UDP,UPNP,SMTP,RTP
WIFI
802.11b,802.11g,(transmission master code stream)support encryption: wep64,wep128,wpa,wpa2 Wifi power:17dbm(54M) Wifi distance:≤70M (Optional)
3G
TD/WCDMA (transmission slave code stream )optional
Audio Talkback Input
1way,3.5mm audio interface(linear, MIC can be switched via dial code)
Audio Output
1way, 3.5mm audio interface(linear)
TF Card Store
TF card support recording store and snapshot,SD2.0 standard,Max capacity 32G,save as slave code stream (Optional)
Pan Rotation
360° continuous pan rotation, Speed: 0.01-350°/S
Tilt Rotation
90° tilt angle, Speed: 0.01-120°/S
Preset Position
256 positions
Cruise Route
8 Lines
Communication terminal
RS485 / RE232
Communication Protocal
PELCO_P, PELCO_D and multi protocal (customize)
Baud rate
1900/4800/9600/19200bps
Intelligence Alarm
motion detection, video mask
Alarm Port
1way input 1way output
Communication Port
RS485 interface,( optional RS232 interface)
Reset
Support one key reset
Working Condition
TEP: -35°C~+55°C, Humidity:<90%, No condensation
Power Supply
DC12V±10%(50W)
Size(mm)
Φ210X303
Weight
3.20KG

   100 meter IR distance Outdoor zoom high speed 720p night vision megapixel waterproof high definition industry security camera

100 meter IR distance Outdoor zoom high speed 720p night vision megapixel waterproof high definition industry security camera
