Auto Tracking Color PTZ USB Video Conference Camera

Auto Tracking Color PTZ USB Video Conference Camera thumbnail-1
Auto Tracking Color PTZ USB Video Conference Camera thumbnail-2
Auto Tracking Color PTZ USB Video Conference Camera thumbnail-3
Auto Tracking Color PTZ USB Video Conference Camera thumbnail-4
Auto Tracking Color PTZ USB Video Conference Camera photo-1
Auto Tracking Color PTZ USB Video Conference Camera photo-2
Auto Tracking Color PTZ USB Video Conference Camera photo-3
Auto Tracking Color PTZ USB Video Conference Camera photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Simultaneous Interpretation:
No
Place of Origin:
Guangdong, China
Brand Name:
Oneking
Contact Supplier Request Quote Chat Now
Shenzhen Oneking Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Simultaneous Interpretation No
Place of Origin Guangdong, China
Brand Name Oneking
Model Number C368
Type Other, Video conference camera

    Auto Tracking Color PTZ USB Video Conference Camera



Product Description



Auto Tracking Color PTZ USB Video Conference CameraFeatures:

  • Smart design Standard Definition PTZ camera
  • Fast and smooth video handling
  • Low cost design for video conferencing
  • Speed Match
  • Auto/Manual IRIS/brightness/WB
  • RS-232C/VISCA Protocol
  • Boundary scanning
  • Image auto-flip

Performance:

  • 650TVL
  • 1/4 Effio-E  CCD
  • Pan ±180degree continuously
  • Tilt +120 degree, - 120 degree
  • 64 preset positions
  • 4 cruise lines
  • DC 12V, 1.2A

Dimension:

  • L 250mm x W 140mm x H154mm
  • N. Weight: 1.4kgs
  • G. Weight: 1.7kgs

Installation:

  • Desktop
  • Ceiling/wall mount
  • Standard Tripod accessory

     Auto Tracking Color PTZ USB Video Conference Camera

Our Services

 Video conference camera Specification sheet



Camera module

C368- 18

Image Sensor

Sensor

1/3’ Sony  CCD

Signal System

PAL/NTSC

Illumination

0.5 Lux

White Balance

Auto/Manual

Gain Control

Auto

Back-light
compensation

On /Off

E-Shutter

1/50-1/10,000s

Horizontal
Resolution

650TVL

S/N Ratio

>50db

Lens

Focus

f=5-90mm F1.6 -3.0

Iris

Auto/Manual

Zoom

18x optical zoom

Video Output

SD:CVBS,S-Video, USB(optional)

Control Decoder

Built-in decoder

Communication
Interface

EIA/RS422, EIA/RS232(Bidirectional)

PTZ Control Protocol

VISCA, PELCO-P, PELCO-D (optional)

Baud Rate

9600/38400bps

Patrol Lines

4 Patrol Lines

Preset Position

64 Preset Position

Power-off Protection

Saved scanning or patrol line settings Automatically Before power off

Speed Matching

Slow down camera Pan/Tilt movement speed while camera zooming in

OSD Menu

To change parameters of camera or camera module from OSD Menu

Image Auto Flip

Image Auto Flip

Pan Speed

1-200° /S

Tilt Speed

1-150°/S

Pan Rotation Angle

360° continuously

Tilt Rotation Angle

Up: 90°, Down: 45°

Auto Pan Scan

Support auto pan scanning

Boundary Scan

0-359° (programmable)

Remoter Control

IR wireless remote controller P/T/Z

Power Supply

DC12V±10%, 1.2A

Working Temperature

0-50°C

Environment Humidity

0-95%RH

Size(LxWxH)

250X140X145mm

Weight

1380g

 Accessories kits in package:

  • 1x C368 Color Video Camera
  • 1x DC 12V/2A Power Adaptor
  • 1x User’s manual
  • 1x Installation brackets & screws
  • 1x RS 232 Control Cable
