SD conference camera 10X Optical zoom 650TVL video conference equipment

Specifications

video conference equipment
a) 10X optical zoom
b) S-Video,VISCA Protocol RS-485/422
c) Wall/ceilling/tripod

We are proffessional manufacturer of Color video conference equipment ----



SD conference camera 10X Optical zoom 650TVL video conference equipment



Brief Description of C360-USB video conference equipment



 Model no.: C-360-USB

10x optical zoom, 650TVL



C-360-USB Color Video PTZ Camera which adopted 10x optical zoom with high performance 650TVL Quality, it equipped with USB video card and provided USB, AV video output both, ideally suited for Web video conferencing system, remote education system etc.







  C360-USB video conference equipment Features:

• 10x Optical Oneking Zoom 650TVL
• Oneking/Samsung/Sony Brands
•  Built in USB Video Card- CD Driver in the package-
• USB/AV Video output- Pan >0~280°/s Tilt >0~100°/s
• 360° continuously Pan rotation
•  Provided wall & ceiling mounting
• IR Remote controller
• Support S-Video RS-232 Visca Protocol



C360-USB video conference equipment Images:







Specification Sheet:



Model		C-360-USB
Image Sensor	CCD	1/4” SONY CCD
	Minimum Scene Illumination	0.01 Lux
	White Balance	AUTO/Manual
	Gain Control	Auto
	Back-light Compensation	On/Off
	Electronic shutter	1/50-1/10,000s
	Horizontal resolution	650 TVL
	S/N Ratio	> 50dB
Lens	Focus	AUTO
	Iris	AUTO/Manual
	Zoom	10 Optical Zoom
		f=3.8-38 mm,F=1.8
Video Output		VIDEO VBS: 1.0Vpp at 75ohm;
		USB interface
Communication		EIA/RS-422
		EIA/RS-232(Bidirectional)
Baud Rate		4800/9600 bps
Patrol tours		4
Pattern tours		4
Preset		64
Privacy Mask Zone		4
Power On Active		Auto pan scan or Patrol(Programmable)
Speed Matching Function		Support
OSD Menu		Support
Image Auto Flip		Support
Pan Speed		0-280 degrees/s
Tilt Speed		0-100 degrees/s
Pan rotation angle		360 degrees continuously
Tilt rotation angle		240 degrees
Auto Pan Scan		Support
Boundary Scan		0-359 degrees(programmable)
Remoter Control		RF Wireless remote control P/T/Z (10M)
Power		DC 12V+-10%;1.2A
Temperature and humidity		0o-60o C,0-95% RH(non-condensation)













































































































1.  Color box with PE Foam, Strong Carton

2. T/T, Western Union, Paypal
