Home > Products > New Products > [KESSEN CERAMIC] honeycomb and foam ceramic filters
![[KESSEN CERAMIC] honeycomb and foam ceramic filters](https://img11.fr-trading.com/3/1_964_21456_750_750.jpg)
[KESSEN CERAMIC] honeycomb and foam ceramic filters
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Type | Ceramic Parts | |
| Application | Industrial Ceramic | Material | Alumina Ceramic | |
| Model Number | KS6549656 | Brand Name | kessen |
Product Description
ceramic heat exchanger
Specifications
Introduction
The honeycomb ceramic as heat exchange media is the key part for heat storage HTAC(High Temperature Air Combustion) technology, which has been widely applied in all kinds of pushing-steel heating furnace, RTO(Regenerative Thermal Oxidation), stepping heating furnace, heat treatment furnace, forging furnace, dissolving furnace, steel wrapping/middle wrapping baking apparatus, soaking pit, radiation tap incendiary apparatus, covering furnace, high temperature hot-blast stove in metallurgical machine building and all kinds of ceramic cellar stove, glass cellar stove in building materials, and all kinds of tap heating stove, splitting stove, other industrial stove cellar, too.
Honeycomb ceramics as heat storage body, by the advantage of large specific surface area, small heat resistance, good thermal conductivity, excellent thermal shock resistance, realize quickly exchanging heat; reducing energy in the strict sense (up to 97% of true thermal energy can be recovery and also it can absorb NOx more than 40%).
Technical Data
Dimension (mm) | Quantity of cells | Wall thickness (mm) | Width of cell (mm) | Surface area (m2/m3) | Void section (%) | Weight per piece (kg) |
150*150*300 | 25*25 | 1 | 4.96 | 580 | 68 | 4.7 |
150*150*300 | 40*40 | 0.7 | 3.03 | 891 | 65 | 5.5 |
150*150*300 | 50*50 | 0.6 | 2.39 | 1090 | 63 | 6.1 |
150*150*300 | 60*60 | 0.5 | 1.99 | 1303 | 63 | 6.3 |
150*100*100 | 40*40 | 1 | 2.5 | 784 | 49 | 1.2 |
150*100*100 | 33*33 | 1.1 | 3 | 691 | 52 | 1.13 |
150*100*100 | 20*20 | 2 | 5 | 392 | 49 | 1.04 |
100*100*100 | 40*40 | 1 | 2.5 | 784 | 49 | 0.81 |
100*100*100 | 33*33 | 1.1 | 3 | 691 | 52 | 0.75 |
100*100*100 | 20*20 | 2 | 5 | 392 | 49 | 0.68 |
Regenerator specification index
| Name | Alumina | Dense Cordierite | Porous Cordierite | Cordierite-Mullite | Dense Alumina | Mullite | Corundum mullite | |
| Density(g/cm3) | 2.0~2.3 | 2.1 ~2.5 | 1.5 ~1.9 | 1.8~2.3 | 2.4 ~2.7 | 2.0 ~2.5 | 2.3 ~2.7 | |
| Coefficient of heat expansion (×10-6K-1) (20~800°C) | ≤5 | ≤3.5 | ≤3.0 | ≤3.5 | ≤5 | ≤5 | ≤6 | |
| Specific Heat (J/Kg.K)(20~1000°C) | 900~1150 | 900~1100 | 900~1100 | 900~1150 | 1000~1150 | 1000~1150 | 1100 ~1300 | |
| Thermal Conductivity (W/m.k) (20~1000°C) | 1.5~2.0 | 1.5~2.5 | 1.2~1.8 | 1.5~2.0 | 1.5~2.5 | 1.5~2.0 | 1.5~2.5 | |
| Impact Thermal Resistance (°C/min) | ≥300 | ≥300 | ≥350 | ≥350 | ≥300 | ≥350 | ≥300 | |
| Max. Working Tem.(°C) | 1350 | 1300 | 1300 | 1320 | 1350 | 1450 | 1550 | |
| water absorption(%) | 15-25 | ≤2 | 15~25 | 15 ~25 | ≤2 | 15~25 | 15 ~25 | |
| compressive strength(MPa) | ≥28 | ≥28 | ≥25 | ≥25 | ≥28 | ≥28 | ≥30 | |
| chemical composition (%) | Al2O3 | 55 ~65 | 25 ~38 | 28 ~38 | 40~52 | 55 ~65 | 60 ~70 | 70 ~80 |
| SiO2 | 25~35 | 50 ~60 | 45 ~55 | 45 ~55 | 25 ~35 | 25 ~35 | 15 ~25 | |
| MgO | 1~3 | 5 ~10 | 11 ~14 | 7~9 | 3~5 | 0 ~1 | 0 ~2 | |
| others | <5 | <5 | <5 | <5 | <5 | <5 | <5 | |
Packaging: Fumigation-free Wooden case.
![[KESSEN CERAMIC] honeycomb and foam ceramic filters](https://res.goldsupplier.com/img/env2/common/load/circle-loading.svg)
Package
Carton,Plywood
Shipping
We can supply you the translation methods whatever you want.
--By express (DHL/Fedex/etc.)
--By Air to your nearest Airport
--By Sea to your nearest Seaport
--By the sellers’ shipping agent
Our products are warranted to be free from defects in materials or workmanship for 6months from the date of purchase. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs.
1.Your inquiry related to our products or prices will be replied within 24hours
2. Guarantee samples quality same as mass production quality
3. Offering the support to solve the problem in the application or selling period.
4. Competitive prices based on same quality.
Shanghai Kessen Ceramics Co., Ltd. is a wholly owned subsidiary of Shanghai Kessen
Group Corp. Professional design, production and sale of precision ceramics, refractory
ceramics, and new inorganic non-metallic materials, that is alumina, zirconia, magnesia,
silicon nitride and silicon carbide as main raw materials. After a series of synthetic and
refining processing to make superfine powder. By means of 1700c ultra-high temperature and
high pressure process sintering, the products have high temperature resistance, corrosion,
wear, pressure insulation and other outstanding features. They are widely used in electronics,
metallurgy, petrochemical, information, mechanical, electrical, autos, aerospace, new energy,
military, defense and other industries.
Shanghai Kessen Group Corp
Shanghai Kessen Ceramics Co Ltd
No1115 Road Yongxin Jiading Shanghai 201800 China
Tel:86-21-51099195 Fax:86-21-51010816 Skype:kessen.alan
1. Can you accept OEM?
Yes!.We can manufacture as per your request specification.
2. Can you deliver the goods via our shipping agent?
Yes, we could help you make the delivery using your shipping agent
3. Can you supply sample?
Yes.We would like to give you suitable suggestion according to your detail application.
4. What about your After-sales service?
Yes.We promise that we can change or refund products if there are any quality problem.
If you need more professional help, please contact us. Our technical engineers would like to give advices according to your requirements
Contact Us
- Shanghai Kessen Ceramics Co., Ltd.
- Contact nameFlynn Shen Chat Now
- Phone86-21-51099195
- AddressNo. 1115, Yongxin Road, Xuhang Town
