Help CenterAutomatic 5000bph Carbonated Drink Bottling Plant
Related Products
-
Carbonated Drinks Production MachineNegotiableMOQ: 1 Set -
PET Bottle Soda Water Production MachineNegotiableMOQ: 1 Set
-
Carbonated Soft Drink Filling Production Line/ PlantNegotiableMOQ: 1 Set
-
Carbonated Drinks Processing LineNegotiableMOQ: 1 Set
-
Carbonated Drinks Washing Filling Capping 3-in-1 Monobloc MachineNegotiableMOQ: 1 Set
Specifications
1.PLC:Mitsubishi, Siemes2.SUS304/316
3.up to 20,000bph
Carbonated drink bottling plant can carry out washing bottle, carbonated filling and capping of one machine. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient. It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and easier. The main machine adopts advanced PLC control technology. The key electric elements are adopting international famous products.
Features of carbonated drink bottling plant:
This equipment combines rinsing bottles, filling bottles and capping bottles together with PLC control. It is mainly used for plastic bottles with carbonated beverages and non-carbonated beverages.
Characteristic of carbonated drink bottling plant:
1. All parts contacting with beverages adopt top grade stainless steels whose surfaces are polished till smooth for easy rinsing. The sealing materials are EPDM rubber.
2. Adopt PLC as center control, make use of pressure transmitter and electromagnetism pneumatic valve to measure liquid level, keep balance of filling pressure to insure stable liquid level.
3. Adopt new type filling valves which are especially designed for plastic bottles. The returned air and the liquid in filling tank are insulated to insure cleanliness of the filled beverages.
4. Adopt advanced magnet clutches for capping with adjustable torsional moment to insure capping safely and reliably.
The composition of equipment:
——washing part
——filling part
——capping part
——pneumatic part
——electricity part
——electricity box par
——main transmission part
——chain box and turnover arc board part
Technical Parameter of carbonated drink bottling plant:
| Model(RFC-C) | 18-18-6 | 24-24-8 | 32-32-10 | 40-40-12 |
| Washing, -Filling-Capping | 18-18-6 | 24-24-8 | 32-32-10 | 40-40-12 |
|
Producing capacity (500ml) |
3000-4000 (bph) |
5000-7000 (bph) |
8000-12000 (bph) |
12000-15000 (bph) |
| Suitable bottle size(mm) | φ =50-108 H=170-340 330ml-2.25L | |||
| Pressure (kg/cm² ) | 2~3 | |||
| Outside vacuum pump power (kw) |
Main motor 4.5kw |
Main motor 4.5kw |
Main motor 6kw |
Main motor 8kw |
|
Overall dimension (mm) (LxWxH) |
2100*1400*2500 | 2460*1720*2650 | 3100*2100*2650 | 3500*2500*2650 |
| Weight(kg) | 2500 | 3500 | 4200 | 5500 |
