Fused Cast High Zirconia Block for Lead Crystal glass furnace
The series of TY-Z are fused cast high zirconia refractories which are specially designed refractory for glass furnace application. Fused cast high zirconia bricks are made of artificial synthesis high purity raw materials through special casting process. The crystalline texture consists of baddeleyite and with the characteristics of excellent high temperature & corrosion resistance, low blister and stoning potential. These advantages can prevent liquid glass from pollution effectively.
Specification
--excellent high temperature & corrosion resistance
--low blister and stoning potential
--high purity raw materials
--wide application in glass industry,ceramic fiber industry and construction field,etc.
Fused Cast High Zirconia Block for Lead Crystal glass furnace
| Item | Z88-WS | Z95-WS | ||
| Chemical Composition % | ZrO2 | ≥ | 89.00 | 93.60 |
| SiO2 | ≤ | 9.00 | 5.30 | |
| Al2O3 | ≤ | 1.00 | 1.00 | |
| Na2O | ≤ | 0.05 | 0.51 | |
| Others | ≤ | 1.60 | 1.0 | |
| Mineral Composition % | Baddeleyite | Typical | 89 | 94 |
| Glass Phase | 11 | 6 | ||
| Physical Properties | Cold Crushing Strength (MPa) | ≥ | 400 | 400 |
| Bulk Density (g/cm³) | Typical | 5.10 | 5.30 | |
| Liner Thermal Expansion (%) | 1000℃ | 0.65 | 0.70 | |
| 1500℃ | 0.10 | 0.30 | ||
Fused Cast High Zirconia Block for Lead Crystal glass furnace Application field
--For high quality and special glass furnaces such as TV glass, Borosilicate glass, Alumina silicate glass, Halogen lighting glass, Opal glass and Fiber glass.
---mainly consists of TY-Z88-WS and Z95-WS, and are used in sidewall, throat cover, throat support, electrode block, dam block parts.
High Zirconia Block have passed the ISO international certified. High purity raw material, scientific formula, advanced technology and professional guide all contribute to our qualified azs blocks production. Over 30 years producing and marketing experience, we have developed stable customer base overseas and kept long-term cooperation. Need refractories for high temperature furnace fuel? Contact us, We will never let you down.
Fused Cast High Zirconia Block for Lead Crystal glass furnace Packaging & Shipping
The High Zirconia bricks are packed on wooden pallet with papers in each layer and PP film wrapped outside of the whole pallet.
Fused Cast High Zirconia Block for Lead Crystal glass furnace
1. Quality assurance, High Zirconia Brick use high grade raw material. All products are ISO qualified.
2. Provide professional designing solution, field technical assitance and any other consulting.
3. Price advantage, provided by manufacturer directly,save much intermediate fees.
4. Professional and experienced service team, specialized in refractory production since 1986.
5. Large production capacity, short lead time of products.
6. 24*7 online service.
7. OEM service available.
