comercial medical lab suction equipment ducted fume cupboards
Huilv™ fume cupboard is of constant supply air hood with auxiliary bye-pass provision. Three sides of the hood are permanently closed and the front side provided with sliding door with 5 mm transparent toughed glass panel in metal frame. The fume chamber will be provided with a powerful centrifugal blower, mounted on top of the hood, suitably designed to create necessary suction pressure so as to force the fumes from the hood to exhaust out in to the atmosphere through the duct. The blower and casing will be made of cold-rolled steel with Epoxy resin coated/FRP finish.
all the fume exhaust hoods are provided with a specially designed under-bench storage cabinet, which acts as a support-stand for bottles, small instruments etc.
FUME HOOD TECHNICAL PARAMETERS
| ParameterModel | TF-1200 | TF-1500 | TF-1800 |
| Overall dimension(L*W*H) | 1200*800*2350 | 1500*800*2350 | 1800*800*2350 |
| Work Area(L*W*H) | 970*635*1185 | 1250*635*1185 | 1550*635*1185 |
| Average Wind Speed | 0.3~0.6M/S(Adjustable) | ||
| Noise level | < 60dB(A) | ||
| Exhaust Air Rate | 1500~3000 m3/h | ||
| Openning Height | 0~750mm(adjustable) | ||
| Exhaust Duct | FRP.With strong resistant to acid and alkali,can be equipped with electric air valve | ||
| Pipe Collar(mm) | φ190 | ||
| Luminance | 30W*1 (>300Lx) | ||
| Glass Window | Use transparent tempered glass,explosion proof,window front with aluminum alloy,smooth and wear resistant | ||
| Power Supply | 220V50Hz( single phase ) or 380V/50HZ( three phase ) | ||
| Motor power consumption | 0.5~1.1KW | ||
| Control Panel | Intelligent control panel | ||
| Socket | 10~15A | ||
| Material | Body:Cold-rolled steel sheet,Powder finish.with excellent chemical resistance and anti high temperature functions Worktops:Using solid chemical resistant Phenolic resin tops |
||
| Standard Accessory | Water tap:one | ||
| Water cup:one | |||
| Control panel:one | |||
| Water proof socket:two | |||
| Optional accessory | various taps and gas valve | ||
| Net Weight(kg) | 200 | 230 | 260 |
| Gross Weight(kg) | 240 | 280 | 320 |
| Package Size | 1340*900*2600 | 1660*900*2600 | 1950*900*2600 |
Remark:According to customer requirement,remote control,sterilization,camera,sound recording function can be equiped with.
4.Walk-in fume hood
Factory Production Process show
Application for our furniture
Our Certificte(customers trusted and quality guarantee factory)
Huilv Laboratory Scientific Cooperation is one of biggest and most professional factories in Guangzhou city ,China from 1995,we have experienced designer team,professional technicians ,volume output productivity,offered turnkey project service from lab design, manufacture, installation and after-sale services
1.Why choose Huilv?
We are the leading manufactuer in lab furniture and lab equipment, OEM & ODM service are offered. And we have our own overseas techinican and installation team.
2.What’s Huilv main products?
We supply laboratory furniture, fume hood, pass box, air shower, emergency shower, clean bench,laminar flow cabinet,etc.
3.How about the sample of Huilv product?
We could send you the samples but the freight and the sample are charged.
4.How about Huilv payment term?
T/T & L/C &Western Union(40% deposit, the balance before shipment)
5.How about Huilv delivery time?
Within 7-15 workdays after receiving deposit.
6.How about Huilv validity of quotation ?
Usually 30 days as the shipping freight and exchange rate can be fluctuant.
7.What is the shipping port?
FOB to Guangzhou or Shenzhen Port,China(also can ship according to customers’ request)
8.How about the package?
Bubble film + Cottom +Standard export wooden case or as your request.
9.How to inspect the goods?
Products will checked by our QC staff frist, then our proejct manager. Client can come and check bythemselves or third party check is available.
Choose Huilv choose professional and profit-Win-Win business!!!
