Specifications
Mathematics Laboratory1) Warranty:5 years
2) CE & TUV & SGS
3)OEM&ODM
4)Payment:T/T, L/C, D/P, Western Union
Product Detail Information
Worktop |
20mm ceramics countertops, most chemicals resistant
|
Cabinet body |
SS, steel, PP, FRP, wood etc
|
|
Dimension
|
1200*800*2350mm |
1500*800*2350mm (or customized) | |
1800*800*2350mm | |
Visual windows |
Transparent tempered glass, explosion-proof
|
Control panel |
Touch, intelligent control panel
|
Handle |
1.C-frame alloy with chrome-plating handle
2.Embedded aluminum alloy handle with epoxy coating
|
| Hinge |
1.175º open type hinge
2.High Quality 304# SS
|
Faucet |
Brass body with ceramic valve core
|
Gas valve |
Solid brass body, high gloss epoxy powder coating
|
Sink |
High grade pp, resistant to most chemicals and organic solvent
|
Socket |
Special lab Multi socket. double electric, international standard
|
|
All structure can be customized
| |
| Model |
TF-1200 / TF1500 / TF1800
|
| Average wind speed |
0.3-0.6m/s adjustalbe
|
| Noise level |
< 60dB(A)
|
| Exhaust air rate |
1500-3000m3/h
|
| Opening height |
0-750mm
|
| Luminance |
>300LX
|
| Power |
(Single-phase)220V/50HZ or (Three-phase)380V/50HZ
|
| Motor power |
0.5-1.1Kw
|
| Weight |
200-250Kg
|
| Socket |
10-15A
|
| Remark |
Remote control, sterilization, camear etc, available
|
2. Worktop Types
We supply different kinds of worktop to needs of various types of laboratories, all this materials are commonly used in the Lab.
Comparison of Worktops' Specifications
| Worktop |
Ceramic 20mm
|
Epoxy resin 15/20/25mm
|
Phenolic resin 12.7/17/19mm | Trespa toplab 13/16/19mm | Stainless steel 1.0/1.2mm | Polypropylene 15/19mm |
| Physical property | ||||||
| Chemical resistance |
Low
|
High | Medium | Medium | Low | High |
| Monolithic |
No
|
Yes | No | No | No | Yes |
| Non porous |
Yes
|
Yes | Yes | Yes | Yes | Yes |
| Flame retardant |
Yes
|
Yes | Limited | Yes | Yes | No |
| Moisture resistance |
Yes
|
Yes | Yes | Yes | Yes | Yes |
| Use in fume hood |
Average
|
Recommended | Average | Recommended | Recommended | Not recommended |
| Type of sinks Recommended to use |
PP & stainless steel
|
Epoxy, PP & stainless steel | PP & stainless steel | PP & Stainless steel | Stainless steel | PP & Stainless steel |
| Application |
More commercial than industrial use for its aesthetic features
|
All areas where high moisture, heat, harsh chemical environment and ease of decontamination is necessary | Wet and common chemical resistant areas | Suitable in wet environment and chemical resistant areas | Suitable in wet environment and ease of cleaning | Wet and common chemical resistant areas |
| Cost evaluation |
Valued at commercial rate, more expensive than expoxy top
|
Cost effective as it gives value and high performance | Value for money as performance is acceptabe to most industrial laboratories | Value for money as performance is acceptabe to most laboratories | More expensive than phenolic resin top as it requires backing ply, conductor for electricity | Expensive as it requires a backing ply sheet |
3. Company Profile
Location:
Modern Production Line:
Certificates:
Packaging:
4. Transaction Details
| Packaging |
Bubble film+Foam+Wooden
|
| Delivery |
7-10 working days
|
| Payment Terms | L/C,T/T,Western Union |
| Port |
Shenzhen, Guangzhou, Shanghai, etc
|
| Warranty |
5 years
|
|
Our after-sale service
| |
| Before sale |
Provide the clients with the professional laboratory design, with the technical parameters' details of products, meanwhile, we will organize observation tour of demonstration project for out clients.
|
| Selling |
The project department with professional engineers keeps in touch with the clients for coordination, to ensure the normal installation and use of laboratory equipments.
|
| After sale |
All products sold by Huilv are entitled to 3 years free warranty and lifelong maintenance service.
|
PS:
Any questions or requires, Please feel freely to contact us.
All of our products are customized!
