Product Details
| Place of Origin: | Guangdong, China | Brand Name: | shenyixin | Model Number: | SYX-SH578 |
| Base Material: | FR4 | Copper Thickness: | 1oz | Board Thickness: | 1.6mm |
| Min. Hole Diameter: | 0.3mm | Min. Line Width: | 0.076mm | Min. Line Spacing: | 0.076mm |
| Surface Finishing: | HASL LF |
Product Description
Specifications
1aluminium pcb board2.HASL,ENIG,Plating gold,etc.
3.1-10 layer board
4.UL,SGS,ROHS,CE Certificate
aluminium pcb board CB Design&Electronic PCB Manufacturer printed circuit board pcb manufacturer
Specifications
1.UL, SGS Test, RoHS Certification, ISO9001:2008
2.1-16 layer:FR-4, Alu pcb
3.Short lead time
4.10 years factory
We can do for you:
1-16 layer FR-4 PCB board, 1-2 layer Aluminum PCB
1-6 oz copper thickness
0.2 mm hole size
0.1 mm track width/space
Our PCBs are used for wide range of electronic products,
Like Medical devices, CCTV, Power supply, GPS, UPS, Set-top Box,
Telecomunication ,LED, etc.
Factory Manufacture Capability.
Item | Manufacture Capability | |
Material | FR-4 / Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3, Aluminium, Metal based | |
Layer No. | 1-16 | |
Finished Board thickness | 0.2 mm-3.8mm’(8 mil-150 mil) | |
| ||
Board Thickness Tolerance | ±10% | |
Cooper thickness | 0.5 OZ-11OZ (18 um-385 um) | |
Copper Plating Hole | 18-40 um | |
Impedance Control | ±10% | |
Warp&Twist | 0.70% | |
Peelable | 0.012"(0.3mm)-0.02’(0.5mm) | |
Images | ||
Min Trace Width (a) | 0.1mm (4 mil) |
|
Min Space Width (b) | 0.1mm (4 mil) | |
Min Annular Ring | 0.1mm (4 mil) |
|
SMD Pitch (a) | 0.2 mm(8 mil) |
|
BGA Pitch (b) | 0.2 mm (8 mil) | |
|
| |
Solder Mask | ||
Min Solder Mask Dam (a) | 0.0635 mm (2.5mil) |
|
Soldermask Clearance (b) | 0.1mm (4 mil) | |
Min SMT Pad spacing (c) | 0.1mm (4 mil) | |
Solder Mask Thickness | 0.0007"(0.018mm) | |
Holes | ||
Min Hole size (CNC) | 0.2 mm (8 mil) | |
Min Punch Hole Size | 0.9 mm (35 mil) | |
Hole Size Tol (+/-) | PTH:±0.075mm;NPTH: ±0.05mm | |
Hole Position Tol | ±0.075mm | |
Plating | ||
HASL | 2.5um | |
Lead free HASL | 2.5um | |
Immersion Gold | Nickel 3-7um Au:1-5u'' | |
OSP | 0.2-0.5um | |
Outline | ||
Panel Outline Tol (+/-) | CNC: ±0.125mm, Punching: ±0.15mm | |
Beveling | 30°45° | |
Gold Finger angle | 15° 30° 45° 60° | |
Certificate | ROHS, ISO9001:2008, SGS, UL certificate | |
