Stabilizer Pcb Designing Smps Pcb Design

Name: Stabilizer Pcb Designing Smps Pcb Design
Brand: Shenyixin
SKU: 110265757
Availability: InStock

US$ 0.01 - 5 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Shenyixin

Model Number:

SYX-058

Shenzhen Shenyixin Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Shenyixin

Model Number SYX-058

Number of Layers 12-Layer

Base Material FR4 PCB

Copper Thickness 0.5oz

Board Thickness 1.0mm

Min. Hole Size 0.1MM

Min. Line Width 3mil

Min. Line Spacing 3mil

Surface Finishing ENIG PCB

stabilizer pcb designing smps pcb design

Our Factory Manufacture Capability

Item	Manufacture Capability
Material	FR-4 / Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3, Aluminum, Metal based/FR1/CEM1/FPC
Layer No.	1-- 20
Finished Board thickness	0.2 mm-4.0mm’(8 mil-160 mil)
Board Thickness Tolerance	±10%
Cooper thickness	0.5 OZ-6OZ (18 um-210 um)
Copper Plating Hole	18-40 um
Impedance Control	±10%
Warp &Twist	0.50%
Peelable	0.012"(0.3mm)-0.02’(0.5mm)
Images
Min Trace Width	0.075mm (3mil)
Min Space Width	0.075mm (3mil)
Min Annular Ring	0.1mm (4 mil)
Solder Mask
Min Solder Mask Dam	0.0635 mm (2.5mil)
Solder mask Clearance	0.1mm (4 mil)
Holes
Min Hole size (CNC)	0.1 mm (4 mil)
Min Punch Hole Size	0.9 mm (35 mil)
Hole Size Tol (+/-)	PTH:±0.075mm;NPTH: ±0.05mm
Hole Position Tol	±0.075mm
Plating
HASL	2.5um
Lead free HASL	2.5um
Immersion Gold	Nickel 3-7um Au:1-5u''
OSP	0.2-0.5um
Certificate	ROHS, SGS, UL, ISO9001: 2008.TS16949
