Specifications
1.Milk Filling Machine2.full auto configuration
3.PLC controled/food grade ss
4.Good quality and service
BW-2200A type machine is fully automatic with top configuration. The entire machine is made of food-grade stainless steel. The surface is special processed, so the appearance is beautiful.
1. Work flow :
Put cardboard into carton holder (manually) → Bottom preforming → Bottom heating and sealing → Ultrasonic capping (Optional)→Filling → Top preforming → Top heating and sealing → Date printing → Finished product
The whole process is controlled by PLC, and only need one person to operate.
2. Suitable for filling:
Milk, yogurt, cream, soya been milk, beaten egg, etc.
3. Technical parameter:
Capacity |
250ml, 500ml, 750ml, 1000ml, 1200ml, 1500ml, 2000ml |
|
Output |
1800-2500 cartons/h |
|
Packing material |
A Type carton |
|
Shelf life |
milk, yogurt: 7--21days ( 2-6°C storage) acid juice: 30–60 days (2-6°C storage) whipped cream: 12 months (-18°C storage) |
|
Capping |
With capping (Optional) |
|
Filling temperature |
Under 50 degree centigrade |
|
Overall power |
25KW (three phases of power electricity) |
|
Compressed air |
Pressure: 1.0-1.4 Mpa |
Flow rate: 1.4-2M3/min |
Cooling water |
Flow volume: ≥40L/ min |
Temperature: ≤15°C |
Size: (L*W*H) |
3.7m*1.6m*2.8m |
|
Net Weight |
3500kg |
|
Installation requirement |
Any smooth floor, such as cement, floor tile, plastic ground, etc. Do not need to make angle. |
|
4. Function:
1. PLC control, only need one worker.
2. Apply Touch screen which shows the relevant information for operator, and makes the operation easy.
3. Automatically record the working status, and can be long-term saved.
4. Automatic lubrication.
5. Automatically failure alarm, diagnosing, and solution indicating.
6. The filling capacity can be adjusted at will.
7. The capping function is optional.
8. Can be installed with remote debugging system, which can solve problems for long distance customers.
