QGF Filling Machine
Production Introduction:
5 gallon filling machine,automatic barrel filling machine,5 gallon filling line,barrel filling machine ,filling machine,filling equipment,filling and sealing machine
This filling line specially produces 5 gallons bottled drinking water,whose types(b/h)are:150 type,,300type,450 type,600type,750 type,1350type and 2100 type.ltintegrates bottle washer,filler andsealer into one unit,in order toachieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and leaching areused in bottle washer,Washing solution can boused circularly.The sealer can seal bottle caps automatically.This line equips with water spraying device tosterilize caps of bottlesin order to ensure those caps are aseptic and healthy,also this line can automatically carry out bottle feeding washing,sterilizing,filling capping,counting and products discharging.It is a new kind of barreled water auto-producting line,which integrates mechanism,electricity and pneumatics technologies together.
Technical Parameters:
| Model | QGF-150 | QGF-300 | QGF-450 | QGF-600 | QGF-1200 | QGF-1500 | QGF-1800 |
| Filling heads | 1 | 2 | 3 | 4 | 8 | 10 | 12 |
| (L)Volume | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| (mm)barrel size | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 |
| (b/n)Capacity | 150 | 300 | 450 | 6000 | 1200 | 1500 | 1800 |
| (Mpa)Gas pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 |
|
(m3min) Gas consumption |
0.37 | 0.67 | 0.6 | 0.8 | 1 | 1.5 | 1.8 |
| (kw)Moto power | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | 13.5 |
| (V)Rated Voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
| (kg)Weight | 680 | 800 | 1500 | 2100 | 3000 | 3500 | 4500 |
Production Detail:
