Automatic Rotary Barreled Drinking Water 5 Gallon Filling Machine

Specifications

5 gallon water bottle filling machine
Capacity:100-1200(B/H)
Certificates:CE
bottle type: PET glass bottle





QGF Filling Machine

Production Introduction:

5 gallon filling machine,automatic barrel filling machine,5 gallon filling line,barrel filling machine ,filling machine,filling equipment,filling and sealing machine

This filling line specially produces 5 gallons bottled drinking water,whose types(b/h)are:150 type,,300type,450 type,600type,750 type,1350type and 2100 type.ltintegrates bottle washer,filler andsealer into one unit,in order toachieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and leaching areused in bottle washer,Washing solution can boused circularly.The sealer can seal bottle caps automatically.This line equips with water spraying device tosterilize caps of bottlesin order to ensure those caps are aseptic and healthy,also this line can automatically carry out bottle feeding washing,sterilizing,filling capping,counting and products discharging.It is a new kind of barreled water auto-producting line,which integrates mechanism,electricity and pneumatics technologies together.



Technical Parameters:

Model	QGF-150	QGF-300	QGF-450	QGF-600	QGF-1200	QGF-1500	QGF-1800
Filling heads	1	2	3	4	8	10	12
(L)Volume	18.9	18.9	18.9	18.9	18.9	18.9	18.9
(mm)barrel size	270*490	270*490	270*490	270*490	270*490	270*490	270*490
(b/n)Capacity	150	300	450	6000	1200	1500	1800
(Mpa)Gas pressure	0.4-0.6	0.4-0.6	0.4-0.6	0.4-0.6	0.6	0.6	0.6
(m3min) Gas consumption	0.37	0.67	0.6	0.8	1	1.5	1.8
(kw)Moto power	1.38	1.75	3.8	3.8	7.5	9.75	13.5
(V)Rated Voltage	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ
(kg)Weight	680	800	1500	2100	3000	3500	4500
