10 inch open frame lcd touch screen monitors

Case/Bezel Color

Silvery or Black

Display Size

10"

LCD Type

TFT LCD

Aspect ratio

4:3

Useful Screen Area

211 mm x 158 mm

Touch panel

Multi-touch Projected Capacitive Flat Screen

Touch response time

10.5ms (typical)

Touch Monitor Dimensions

368x 309x237 mm

LCD panel Pixel pitch

0.264 x 0.264 mm

LCD panel Colors

16.2 million

LCD panel Brightness

230 cd/m2

LCD panel Response Time

8 ms

Viewing Angle

(typical, from center)

Horizontal (left/right)

±60° or 120° total

Vertical (up/down)

35°(up), 65°(down) or 100° total

Contrast Ratio

500:1

Output Interface

Mini D-Sub 15-Pin VGA type/ Audio/Mic

Input Interface

USB*3

Net

Wifi and 3G Card(optional)

Camera pixel

2M,5M(optional)

Power Supply Type

Internal Battery DC 12V 10A(optional)

External AC to DC power brick

Monitor input: +12VDC ±5%,3.0 A; DC Jack (2.5)

AC to DC power brick input: 100-240 VAC, 50/60 Hz

Power dissipation: 40W max

ECM

(Embed Computer Modul)

ECM1: Intel® processor P7500 (1.8GHz Dual Core);

ECM2: Intel® processor P7550 (2.26GHz Dual Core); HardDisk:320G;Rom:2G(DDR3,max6G);            Operation System:Win7XpVistaLinux

ECM3: Android A8 1.5G, Flash 4G

ECM4: Android dual core 2G, Flash 4G

Operation System: 4.04

Temperature

Operating: 0°C to 40°C ;Storage -20°C to 60°C

Humidity (non condensing)

Operating: 20%-80%; Storage: 10%-90%

Shipping Carton Dimensions

490 x 440 x340 mm

Weight (approx.)

Actual: 6 kg ;Shipping: 8.5 kg

Warranty Monitor

3 years(Except for LCD panel 1 year)

Backlight lamp life: typical 50,000 hours to half brightness

Agency Approvals

CE/FCC Rohs

Mounting Options

75 mm and 100mm VESA mount
