Mineral Liquid Mixer Agitator Equipment
US$ 1,000 - 999,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Planetary Mixer
Product Type:
Other, Slurry mixing
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai qingdao dalian etc. for liquid mixer agitator
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Lipu Small Flotation Machine for Ferrous MetalUS$ 10,000 - 999,999MOQ: 1 Set -
Shanghai Impact Crusher Manufacturer With Latest TechnologyUS$ 1,000 - 99,999MOQ: 1 Set
-
World Class Mechanical Feeder for Ore DressingUS$ 1,000 - 99,999MOQ: 1 Set
-
Linear Dewatering Machine for Fine SandUS$ 1,500 - 999,999MOQ: 1 Set
-
New Feeder Vibrator DesignUS$ 1,500 - 99,999MOQ: 1 Set
Condition
New
Mixer Type
Planetary Mixer
Product Type
Other, Slurry mixing
Application
Other, Liquid with Suspended Solids, Mix drug and slurry
Additional Capabilities
Granulating
Place of Origin
Shanghai, China
Brand Name
LIPU liquid mixer agitator
Model Number
XB series liquid mixer agitator
Max. Loading Capacity
0.098-30m3
Voltage
According to model
Power(W)
1.5-30kw
Dimension(L*W*H)
According to capacity
Certification
ISO9001:2000
Warranty
1year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
liquid mixer agitator1.Model:XB series;
2.Volume:0.098-30 m3;
3.Internal diameter:500-2500mm;
4. Application:mix slurry
Brief Introduction Of liquid mixer agitator :
liquid mixer agitator is mainly used to mix slurry before flotation in the beneficiation process. It can mix drug and slurry completely. It is suitable to mix slurry with density smaller than 30 % (weight ratio) and size smaller than 1mm. V-belt of motor drives impeller to mix drug and slurry completely. This machine can increase reaction time and strengthen reaction quality of the drug.
Product parameter of liquid mixer agitator :
| Model | Internal diameter (mm) | Internal Height (mm) | Volume (m3) | Impeller speed (r/min) | Impeller diameter (mm) | Weight (t) | Motor power | Dimension (LxWxH) (mm) | |
| Model | Power(KW) | ||||||||
| XB-500 | 500 | 500 | 0.098 | 600 | 200 | 0.15 | Y90S-6 | 1.1 | 600×566×954 |
| XB-750 | 750 | 750 | 0.33 | 530 | 255 | 0.6 | Y90L-4 | 1.5 | 1131×880×1241 |
| XB-1000 | 1000 | 1000 | 0.58 | 530 | 255 | 0.99 | Y90L-4 | 1.5 | 1131×1130×1492 |
| XB-1200 | 1200 | 1200 | 1.4 | 300 | 400 | 1.05 | Y132S-6 | 3 | 1500×1480×1800 |
| XB-1500 | 1500 | 1500 | 2.2 | 320 | 400 | 1.2 | Y132S-6 | 3 | 1750×1640×2190 |
| XB-2000 | 2000 | 2000 | 5.46 | 230 | 550 | 1.6 | Y132M2-6 | 5.5 | 2380×2162×2850 |
| XB-2500 | 2500 | 2500 | 11.2 | 230 | 650 | 3.44 | Y160L-6 | 11 | 3036×2716×3543 |
| XB-3000 | 3000 | 3000 | 19.1 | 210 | 700 | 4.61 | Y225S-8 | 18.5 | 3604×3216×4250 |
| XB-3500 | 3500 | 3500 | 30 | 230 | 850 | 7.28 | Y225M-8 | 22 | 3940×3766×5386 |
Any change of technical parameters, there is no further notice.
Latest Image of liquid mixer agitator :
