Alloy Steel Load Pin Loadcell Sensor for Rigging

Name: Alloy Steel Load Pin Loadcell Sensor for Rigging
Brand: SILVANUS
SKU: 110203523

Alloy Steel Load Pin Loadcell Sensor for Rigging thumbnail-1

Alloy Steel Load Pin Loadcell Sensor for Rigging photo-1

US$ 90 - 120 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

SILVANUS

Model Number:

ZXC

Contact Supplier Request Quote Chat Now

Silvanus Electric Manufacture (Yixing) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name SILVANUS

Model Number ZXC

Usage Pressure Sensor

Theory Resistance Sensor

Output Analog Sensor

alloy steel load pin loadcell sensor for rigging 2t,3t,4t

ZXC Load Cell Features :

Hermetically sealed

Max. Capacities :2,3,4t

Safe and reliable, good stability

To replace the original axis function, and the forcemeasuring and weighing

Suitable for all kinds of crane, hoisting mechanism, rigging shackle, dynamic, and slide of ships with rigging, a connecting fork, rings etc

ZXC Load Cell Application :

truck scales,rail scales,bin and hopper scales,etc.

ZXC Load Cell Dimensions(mm):

ZXC Load Cell Specifications:

Emax(Max. capacity)	t	2,3,4
Sensitivity	mV/V	1.0±0.002
Accuracy class		D1	C1
Maximum number of verification intervals	nmax	2000	3000
Minimum load cell verification interval	Vmin	Emax/2000	Emax/3000
Combined error	%F.S	≤±0.1	≤±0.05
Creep	%F.S/30min	≤±0.1	≤±0.05
Temperature effect on sensitivity	%F.S/10°C	≤±0.03	≤±0.03
Temperature effect on zero	%F.S/10°C	≤±0.03	≤±0.03
Zero balance	%F.S	±1.0
Input resistance	Ω	380±10Ω
Output resistance	Ω	350±3Ω
Service temperature range	°C	-30...+70
Safe overload	%F.S	120
Ultimate overload	%F.S	200
Recommended excitation voltage	V	5…15
Insulation resistance	MΩ/50V	>5000
Protection class		IP66
Load cell material		Alloy steel
Cable length	m	4
Cable outer caliber	mm	Φ5

Packaging & Delivery

PACKAGE:

DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
