load cell Current board sw322
load cell Current board Features:
1.Product name:2~15mA Three wire system current loop template
2.Product No.:SW-322A
3.Function:The sensor voltage signal is Amplified the voltage singal of load cell and transform
Current loop signal transmission in long distance
4.Size:L×W×H = 44×21×7 mm
5.Load Cell Technical Parameter:
1)Input resistance=380Ω;Output resistance=350Ω;
2)Load cell zero input range:-0.1~0.1 mV/V.
3)Load cell sensitivity range:1.8~2.2 mV/V.
6. working condition after connecting load cells:
1)Working power suplly voltage:12V DC;
2)Current loop load resistance:≤300 Ω;
3)when load cell is no-load,Output terminal is is 2±0.05mA current
4)when load cell is full-load,Output terminal is 15±0.05mA current;
5) linear error: ≤0.2%; resultant error:≤0.5% @20℃.
6)temperature property:≤0.2%/10℃.
7) operating temperature range:-15℃~+50℃.
8) storage temperature range:-40℃~+90℃.
Specification:
Circuit board wiring diagram
Packaging & Delivery
Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
