4-20ma weight transmitter sw04B
Full digital processing, multifunction weight transimitter, adapt SMT reflow soldering process to achieve the analog signal of weighing sensor, RS232 or RS485 digital signal transofrm into a standard analog signals and switch output, can be easily connected to the PLC and other industrial equipment support.
Specification:
1)12~24v power supply
Supply power 12v: drive 350Ω 4pcs Load cell ,750Ω 8pcs Load cell
Supply power 24v: drive 350Ω 1pcs Load cell ,750Ω 2pcs Load cell
2)Weight transform use 24 bit Σ-Δintegration ADC chip
3) full digital conversion, don’t have potentiometer and other simulate adjust parts
4) analog quantity output two keys adjust, only need one time to adjust zero point and full value
5)Over width zero.tare rang(0~8mv)
6)Over width full capacity signal rang(1~15mv)
special order ,max supply 400MV)
7) load:4~20mA, 0~20mA :≤550Ω;
0~5V, 0~10V: ≥10KΩ;
8)size:85×58×33mm;
9) operate by key, supply any weight calibrate
RS232 or RS485 support any point to calibrate
10) Voltage analog output , short circuit protection
