Help CenterHongtech H-700 Frame Machine Car Bench Bodybench
Related Products
-
H-600 Frame Machine Car Bench Body BenchUS$ 4,000 - 60,000MOQ: 1 Unit -
Hongtech H-500 Frame Machine CAR BENCHUS$ 4,000 - 6,000MOQ: 1 Unit
-
K600 Frame Machine Truck Repair BenchUS$ 40,000 - 60,000MOQ: 1 Unit
-
Car Aligner Platform, Car Body Repair LifterUS$ 100 - 20,000MOQ: 1 Unit
-
H-500 Frame Machine/tilting Car BenchUS$ 1,000 - 15,000MOQ: 1 Unit
hot sale frame machine
The H-700 series of car collision repair system offers a unique first-class product which operators have no worries of work.
It'smade of industrial and quality manganese steel which the surface andunder-surface plate are in the same thickness.5900mm length and 2100mmwidth platform will meets most collision repairing requirements.
Ithas an parallel lift with 25ton lifting capacity loads carseasily,varies of openinges on the platform provide greateraccessibility to the vehicle for repairs,a faster and strongeranchoring system with fewer bolts to secure the vehicle to the deckplatform.
Tower with integrated roller bearing circumnavigate theplatform smoothly and effortless operation.Variable-position pullcollars provide for unlimited positioning for the correct pulls whenmaking 10ton pulls at the hook.Overhead boom with patented wheel isquite useful for the high roof cars.
Plenty of striking and forged pulling accessories proof-tested with powerful strength.
Oneloading package includes winch,wheel stands,car dollies and secondarybag air jack,is a standard parts for H-700L & H-700M.
- Convenient and accurate measuring system in the industry.
- Most efficient pulling system in the world.
- Comprehensive vehicle database(Mitchell).
- Fast and easy anchoring clamp.
- National service support network.
Technical Data
| Parameters | Data |
| Platform length | 5900mm |
| Platform width | 2100mm |
| Platform height | 300-1200mm |
| Hydraulic pressure | 70Mpa(10000psi) |
| Max.pulling | 95KN(10Ton) |
| Pulling radius | 360° |
| Pneumatic | 0.8Mpa |
| Max. lifting weight | 3000KG |
| Total weight | 3400KG |
Parts No.
BB-700 Platform
BB-1 Pulling Tower(without overhead boom)
BB-2 Pulling Tower(with overhead boom)
BB-3 Ramps
BB-5 Main Clamp
HP-1 EGOR-PRO Hydraulic Pump (H-700C Equipped)
HP-2 USA Pump (ENERPAC,H-700L and H-700M Equipped)
RB-1 Roller Bridge
WB-1 Wheel Bracket
AJ-1 Air Secondary Jack(H-700L and H-700M Equipped)
MS-1 2-Dimesion Measuring System(with Mitchell Database)
BB-7 10pcs Pulling Tools Set(H-700C Equipped)
BB-8 17pcs Pulling Tools Set(H-700L and H-700M Equipped)
MW-1 Manual Winch
Optional Parts No.
MS-2 3-Dimesion Measuring System(with Mitchell Database)
SC-1 Benz Special Clamp
SC-2 BMW Special Clamp
DHC-1005 Ball Pivot
DHC-1405 Trunk Clamp
DHC-1908 Fasten Clamp
EW-1 Electric Winch
