H-800 3 pulling tower car bench
The H-800 series of car collision repair system offers a world-class product in which operators can have complete confidence.
Made from industrial quality manganese steel plate and has a 6200mm long and 2200mm wide platform.
The platform has a parrallel lift system so that vehicles can be easily loaded. The vehicle chassis can be quickly fastened to the platform with
Easy –to-use clamps.
The towers have integrated roller bearings to easily circumnavigate the platform. Variable-position pull collars provide for unlimited positioning for making the correct pull. Overhead boom with patented wheel is quite useful for the high roof cars.
Unit supplied with a comprehensive range of accessories.
- Convenient and accurate measuring system.
- Most efficient pulling system in the world.
- Comprehensive vehicle database (Mitchell).
- Fast and easy anchoring clamps.
- National service support network.
Technical Data
Parameters |
Data |
Platform length |
6200mm |
Platform width |
2200mm |
Platform height |
300-1500mm |
Hydraulic pressure |
70Mpa(10000psi) |
Max.pulling |
95KN(10Ton) |
Pulling radius |
360° |
Pneumatic |
0.8Mpa |
Max. lifting weight |
3000KG |
Total weight |
4100KG |
Parts No.
BB-800 Platform
BB-1 Pulling Tower(without overhead boom)
BB-2 Pulling Tower(with overhead boom)
BB-3 Ramps
BB-5 Main Clamp
HP-1 Eagle-PRO Hydraulic Pump (H-800C Equipped)
HP-2 USA Pump (ENERPAC,H-800L and H-800M Equipped)
RB-1 Roller Bridge
WB-1 Wheel Bracket
AJ-1 Air Secondary Jack(H-800L and H-800M Equipped)
MS-1 2-Dimesion Measuring System(with Mitchell Database)
BB-7 10pcs Pulling Tools Set(H-800C Equipped)
BB-9 20pcs Pulling Tools Set(H-800L and H-800M Equipped)
EW-1 Electric Winch
MPS-1 Multi-point Pulling System
UM-1 User Manual Book
Optional Parts No.
MS-2 3-Dimesion Measuring System(with Mitchell Database)
SC-1 Benz Special Clamp
SC-2 BMW Special Clamp
DHC-1005 Ball Pivot
DHC-1405 Trunk Clamp
DHC-1908 Fasten Clamp
MW-1 Manual Winch
