Specifications
1. Weight: 150 g2. Dimensions: 100 x 48 mm
3. Supply voltage: 9-30 V
4. Connection: 2-wire
5. Indication: Red LED
ARTON based in Chernivtsi, Ukraine began over 13 years ago. Our founder and CEO has an engineering background and strong working knowledge of plastic moulding, electrical and optical devices construction. He saw the perspective in the security industry by the rapid growth. ARTON under his leadership has grown from its small beginnings to become the leading brand in its field. ARTON designs, manufactures and markets fire alarm and security devices (conventional photoelectric smoke, heat, combined detectors, manual call points, fire alarm control panels, intruder detectors, accessories etc.).
Product Types:
1. Fire Detectors
2. Fire Alarm Control Panels
3. Accessories, etc.
2-Wire Conventional Smoke Photoelectric Alarm Detector:
Microprocessor intellectual smoke detector
2 sensitivity levels
Twist-lock base and traditional base
Indicates 5 modes
Features:
Designed for detection of low concentrated smoky fires inside premises including unheated premises and for transmission of FIRE notification to FACP.
The detector operates in conventional fire alarm loops with ARTON-0XF control panels detecting activation of one or two and more detectors in AL without fitting current limiting resistor in the circuit, and also with FACP from other manufacturers, detecting activation of one or two and more detectors in AL provided CLR installed in the loop.
The detector operates in AC fire alarm loops.
SPD-3 Elite is an intellectual microcontroller device featuring wide range of technical and user features: higher immunity to industrial range EMP, drift compensation, self-test for proper operation, indication of the current detector’s status.
One of two sensitivity levels can be set with the help of computer: normal and high.
The detector indicates the following modes of operation: Standby, Prealarm, Alarm, Fire, Fault, and allows connecting of remote LED indicator.
When the measuring system operates improperly or in the condition of ultimate drift compensation the detector indicates the fault status with short yellow LED flashes and also sends the fault signal to FACP.
Two types of bases are compatible with the detector: traditional screw and screwless (twist-lock).
You can use K-MK mounting rings for installation to suspended ceilings, into which the detector’s base is secured.
Technical Specification:
Sensitivity (two levels): high (0,08 dB/m), normal (0,12 dB/m)
Voltage range: 9-30 V
Alarm current consumption at Upow (from 12 to 15)V: 10±1 mA
Alarm current consumption at Upow (from 9 to 30)V: 10±2 mA
Alarm current consumption through remote output: 10±2 mA
Outgoing signal conditioning: Non-contact
Connection: 2-wire
Built-in drift compensation in accordance with EN 54-7: yes
Measurement system monitoring: yes
High EMI immunity: IV level
Operating temperature range: -20 ÷ +55 °c
Dimensions: Ø100 X 48 mm
Weight: 150 g
Specification:
| Place of Origin | Ukraine |
| Brand Name | ARTON |
| Model Number | SPD-ELITE |
| Colour | White |
| Weight | 150 g |
| Dimensions | 100 x 48 mm |
| Supply voltage | 9-30 V |
| Indication | Red LED |
| Operating temperature | from - 20 to 55 degree |
| Connection | 2-wire |
| Minimum Order Quantity | 500 Piece/Pieces |
| Port | Odessa |
| Packaging Details | 25 pcs in carton |
| Delivery Time | 2-4 weeks |
| Payment Terms | L/C,T/T |
| Supply Ability | 100000 Piece/Pieces per Month |
