Home > Products > Plastic Mould Steel Plate / Plate bar /Round bar > mould steel flat 1.2344,AISI H13/DIN 1.2344/SKD61/4Cr5MoSiV1/8407
mould steel flat 1.2344,AISI H13/DIN 1.2344/SKD61/4Cr5MoSiV1/8407
- 10000 Metric Ton / Metric Tons per Month
- shenzhen
- T/T
- Hot dip galvanized power engineering Q235 flat iron customized lightning rod tower galvanized flat steel 60 * 6 pre embedded flat steel
- Flat steel Q235 4 x 50mm 100x10mm 90x9mm 75x10mm all size high quality flat steel bar price per ton
- Q195 Q235 Q345 flat steel bars S275JR hot rolled steel galvanized coated carbon steel flat bar
- ASTM Q195 Q215 Q235 Q255 carbon flat steel 1055 1095 hot rolled carbon steel flat bar
- Q195 Q235 hot rolled flat carbon steel flat oval steel tubing sizes special-shaped flat steel
- Hot rolled customized 40mm 50mm black galvanized flat bar steel billets in stock 5.8m
Product Details
Grade: | hot work tool steel | Standard: | AISI, ASTM, DIN, GB, JIS | Thickness: | 20-400mm |
Width: | 200-2300mm | Length: | 2000mm-5800mm | Place of Origin: | China |
Brand Name: | Circle Four | Model Number: | H13/1.2344/SKD61/4Cr5MoSiV1/8407 | Application: | tool steel bar |
Technique: | Hot Rolled | Special Use: | Mold Steel |
Product Description
Specifications
mould steel flat 1.23441.100% UT test.
2..Best offer,excellent quality.
mould steel flat 1.2344
1. Specification:
Material: | H13/SKD61/4Cr5MoSiV1/1.2344/8407 |
Process: | EAF + LF + VD + HOT ROLLED + Heat Treatment (optional) |
Thickness: | 20-400mm, or customer’s request |
Width: | 200-2300mm, or customer’s request |
Length: | 2000mm-5800mm , or customer’s request |
Round: | Diameter 20-300mm, Length 2000-3500mm |
Heat treatment: | Normalized / Annealed / Quenched / tempered |
Delivery condition: | Hot rolled or forged +Rough machined (black surface after Q/T)+ Turned (optional) |
Technical Data: | According to the customer's requirement of Chemical Composition, Physical Properties and Mechanical Testing |
Test: | Ultrasonic test according to SEP 1921-84 GR3 C/C Or SEP 1921-84 Class D/d |
Delivery time: | 7-15 days after advanced payment |
Payment: | 30% advance by TT; Balance pay before the shipment against shipping documents or irrevocable LC at sight |
2.Chemical analysis:
C% | Mn% | Si% | Cr% | V% | Mo% | P% | S% |
0.37-0.42 | 0.30-0.50 | 0.90-1.20 | 4.80-5.50 | 0.90-1.10 | 1.20-1.50 | ≤0.03 | ≤0.03 |
3.Compared grades(based on usage)
Chinese | American | German | Swedish | Japanese |
GB | AISI | DIN | ASSAB | JIS |
4Cr5MoSiV1 | H13 | 1.2344 | 8407 | SKD61 |
4. About us:
◊Establish: Dongguan Circle Four Metal Materials Co., Ltd. was established in 2008 has 5 years manufacturing and exporting professional experience in mould steel, special steel etc.
◊Products: We mainly manufacture more than 100 kinds of hot rolling or forging products, such as alloy structural steel, alloy tool steel, carbon structural steel, carbon tool steel, plastic mould steel, hot work steel, cold work steel, spring steel and high speed steel.
◊Capacity: 500, 000MT per year.
5. Contact us:
Email: gerrycheng(at)
Skype: gerrycheng2011
Phone No.: 86-13794981366
Our factory now equiped with large-sized Vertical sawing machines,Horizontal saw machines,Milling machines,Grinding machines,Finish milling.
We do hardness testing of processing for your needs and we also have advanced ultrasonic flaw detection equipment.
Our products have selling to:
Indonesia,Singapore,Japan,Korea,India,Malaysia,Mexico,Brazil,Denmark,Turkey,Germany,Italy,Dubai,the middle east and other regions.
Contact Us
- Dongguan Circle Four Metal Materials Co., Ltd.
- Contact nameJOEY ZHANG
- Phone086-0769-85313622
- Addresschangan Dongguan,Guangdong
