Home > Products > Plastic Mould Steel Plate / Plate bar /Round bar > steel sheet P20+Ni/1.2738
steel sheet P20+Ni/1.2738
- 20000 Ton / Tons per Month
- shenzhen
- T/T
Product Details
Standard: | AISI, DIN, GB, JIS, Other, AISI, DIN, GB, JIS, ASSAB | Grade: | 3Cr2MnNiMo,P20+Ni,1.2738,718 | Thickness: | 20-400mm |
Place of Origin: | Shanghai, China | Brand Name: | Circle Four | Model Number: | 3Cr2MnNiMo,P20+Ni,1.2738,718 |
Type: | Steel Plate | Technique: | Hot Rolled | Surface Treatment: | Coated |
Application: | Other, Mould Making | Special Use: | High-strength Steel Plate | Width: | 200-2300mm |
Length: | 2000-5800mm |
Product Description
Specifications
steel sheet P20+Ni1. UT test grade: SEP 1921-84 Class C/c
2. Payment terms:TT/LC at sight
3. Best price
steel sheet P20+Ni
1. Specification:
Material: | 3Cr2MnNiMo/ASTM P20+Ni/718/1.2738 |
Process: | EAF + LF + VD + HOT ROLLED + Heat Treatment (optional) |
Thickness: | 20-400mm, or customer’s request |
Width: | 200-2300mm, or customer’s request |
Length: | 2000mm-5800mm , or customer’s request |
Heat treatment: | Normalized / Annealed / Quenched / tempered |
Delivery condition: | Hot rolled/forged +Rough machined (black surface after Q/T)+ Turned (optional) |
Technical Data: | According to the customer's requirement of Chemical Composition, Physical Properties and Mechanical Testing |
Test: | Ultrasonic test according to SEP 1921-84 GR3 C/C |
Delivery time: | 7-15 days after advanced payment |
Payment: | 30% advance by TT; Balance pay before the shipment against shipping documents or irrevocable LC at sight |
2.Chemical analysis
C% | Mn% | Si% | Cr% | Ni% | Mo% | P% | S% |
0.32-0.40 | 1.10-1.50 | 0.20-0.40 | 1.10-2.00 | 2.90-3.50 | 0.30-0.55 | ≤0.03 | ≤0.03 |
3.Compared grades(based on usage)
Chinese | American | German | Swedish | Japanese |
GB | AISI | DIN | ASSAB | JIS |
3Cr2MnNiMo | P20+Ni | 1.2738 | 718 | NAKS5 |
