Wired / Wireless Digital Video Server With Storage

Wired / Wireless Digital Video Server With Storage thumbnail-1
Wired / Wireless Digital Video Server With Storage photo-1
US$ 50 - 500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
K&D
Model Number:
KD-DS101DT-W
Contact Supplier Request Quote Chat Now
Shenzhen Guowei Security Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name K&D
Model Number KD-DS101DT-W
Type Other, network video server
Style Box Camera
Sensor Other, NO
Technology Other, NVS
Special Features Other, Support mobile phone monitor

Specifications

H.264/ MJPEG option
Built-in standard SATA port for HDD
Wired / Wireless Digital Video Server with Storage

;

Mode

KD-DS101DT-W; KD-DS102DT-W; KD-DS104CT-W; KD-DS104DT-W;KD-DS101DT; KD-DS102DT; KD-DS104CT; KD-DS104DT

Video Input

1/2/4 channel composite video, PAL or NTSC                                                         BNC interface,1.0Vp-p,impedance 75Ohms

Video compression

H.264 Main Profile @Level 3 /  MJPEG

Dual-Streaming

H.264/ MJPEG option

Video Definition

PAL: 352*288 (CIF), 704*288 (2CIF), 704*576 (D1);
NTSC: 352*240 (CIF), 704*240 (2CIF), 704*480 (D1)

Video Parameters

Brightness, Hue, Contrast, Saturation, Image quality.

Streaming Format

Optional Video Streaming or Audio &Video composite Streaming

Video Frame Rate

PAL: 1-25 frames/second ; NTSC:1-30 frames/second

Video Compression Bit rate

32Kbps~16Mbps

Video Output

1 compound video, PAL or NTSC; BNC, level: 1.0Vp-p, impedance: 75Ω,

Audio Compression

G.726, G711, ADPCM

Audio Input

12/4 channel, RCA port, liner input, Impedance:1KOhms

Audio Output

1channel,RCA port, linear output

Audio talk-back input

1 channel ,MIC port

Overlaid Caption

Channel, Date, Bit rate. position adjustable

Communication Interface

1 10M/100M self-adapting Ethernet port, RS485 port, RS232 port               Built-in some high-speed protocols and decoding protocols.                     Support public protocols.                                                  Support CDMA, GPRS mobile network.                                     supports 802.11b/g protocol, 2.4GHz, maximum wireless distance can be 100 meters, Supports WEP,WPA,WPA2(support wireless model)

Storage interface

Built-in standard SATA port for HDD.                                                Support SD card storage and snapshot, SD2.0 standard. (Max 32G SD card),     Support FTP server.

Supports smart mobile monitor that is based on  Windows Mobile, Symbian and  iPhone platforms

Alarm Input

4 channel on/off input, supporting NO (normally open) or NC (normally close) sense.

Alarm Output

4 channel on/off output,120VAC 1A/24VDC 1A

Alarm Message

Sending alarm message by Email.

Input Power Supply

DC 12V,3A

Maximum Power

Less than 15W

Operating Temperature

-10 ~ +55°C

Operating Humidity

RH90%MAX

Dimension

33Cm(L) * 20Cm(W)* 4.8Cm(H)

Net weight

1.82kg
