IP Network Video Server Cameras

IP Network Video Server Cameras thumbnail-1
IP Network Video Server Cameras photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
K&D
Model Number:
KD-DP32DX
Contact Supplier Request Quote Chat Now
Shenzhen Guowei Security Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name K&D
Model Number KD-DP32DX

Specifications

Encoder and Decoder Platform,Support 8CH D1 or 8ch CIF encoder cards,Support 8 pcs Decoder cards

Model

KD-DP32DX

Video Input
(encode platform)

32channel composite video, PAL or NTSC
BNC interface ,1.0Vp-p,impedance 75Ohms

Video compression

H.264 Main Profile @Level 3/MJPEG optional

Video Distinguish Rate

PAL;352*288CIF,704*288 2CIF,704*576 D1
NTSC;352*240 CIF,704*240 2CIF 704*480 D1

Adjustment of
Video Parameters

Brightness ,Hue, Contrast, Saturation, Image quality.

Streaming Format

Optional Video Streaming or Audio &Video composite Streaming

Video Frame Rate

PAL:  1-25frames/second;
NTSC;1-30frames/second

Video Compression Bit rate

16Kbit/S??4Mbit/S

Video  Output
(decode platform )

8 channel composite video, PAL or NTSC BNC interface ,1.0Vp-p, impedance 75Ohms

Audio Input

32 channel ,RCA interface, liner input, Impedance:1KOhms

Audio Compression

MP3

Audio Output

8channel,RCA interface, linear output

Audio talk-back input

8channel ,MIC interface

Communication Interface

8 10M/100M self-adapting Ethernet ports ,8RS485 port,8 RS232 port
Several built-in high-speed dome and decoder protocols, supports transparent  protocols;. Supports 802.11b/g wireless network; Supports CDMA1X.GPRS mobile network.; Supports surveillance via the mobile phone.

Supports smart mobile monitor that is based on  Windows Mobile, Symbian and  iPhone platforms

Alarm Input

32channel on/off input, supporting NO(normally open) or NC(normally close) sense.

Alarm Output

16 channel on/off output,120VAC 1A/24VDC 1A

Input Power Supply

AC 100/240V/50/60Hz

Maximum Power

Less than 40W

Operating Temperature

-10 ~ +55 °C

Operating Humidity

RH90%MAX

Dimension

57cm(L)X50cm(w) X22,5cm(H)
