Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)

Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) thumbnail-1
Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) thumbnail-2
Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) thumbnail-3
Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) thumbnail-4
Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) photo-1
Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) photo-2
Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) photo-3
Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0) photo-4
US$ 1 - 300 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Dahua
Model Number:
NVR5208/5216/5232(-8P)-4KS2
Contact Supplier Request Quote Chat Now
Shenzhen Guowei Security Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Dahua
Model Number NVR5208/5216/5232(-8P)-4KS2
Type Other, nvr
Style Other, nvr
Sensor Other, Embedded processor
Technology NetWork
Special Features Waterproof / Weatherproof

Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)

To Know,To Trust,your reliable security partner!

Skype:nickyzhou688668

Email:nicky(at)

Whatsapp:0086 131 4599 7168

Best service for you~



NVR5208/5216/5232(-8P)-4KS2

Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)

Features:



  >Up to 8/16/32 channel IPC input
> H.265/H.264/MJPEG/MPEG4 codec decoding
> Max 320Mbps incoming bandwidth
> Up to 12Mp resolution preview&playback
> Max 16ch@1080P H.265/H.264 decoding
> HDMI/VGA simultaneous video output
> 4/8/16 channel synchronous realtime playback, GRID interface
> Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc.
> ONVIF Version 2.4 conformance
> 3D intelligent positioning with Dahua PTZ camera
> Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)
> Support IPC UPnP, 8PoE ports for PoE model
> Multiple network monitoring: Web, CMS(DSS/Smart PSS) & Mobile phone (DMSS)


 Specifications:



ModelDH-NVR5208-4KS2
DH-NVR5208-8P-4KS2		DH-NVR5216-4KS2
DH-NVR5216-8P-4KS2		DH-NVR5232-4KS2
DH-NVR5232-8P-4KS2
System
Main ProcessorQuad-core embedded processor
Operating SystemEmbedded LINUX
Video& Audio
IP Camera Input8 channel16 channel32 channel
Two-way Talk1 channel Input, 1 channel Output, RCA
Display
Interface1 HDMI (up to 3840x2160), 1 VGA
Resolution3840x2160, 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split1/4/8/91/4/8/9/161/4/8/9/16/25/36
OSDCamera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
CompressionH.265/H.264/MJPEG/MPEG4
Resolution12Mp/8Mp/6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1&etc.
Record Rate320Mbps
Bit Rate16kbps~ 20Mbps for per channel
Record ModeManual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger EventsRecording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
Video DetectionMotion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input4 channel
Relay Output2 channel
Playback & Backup
Sync Playback1/4/81/4/8/161/4/8/16
Search ModeTime/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback FunctionPlay, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup ModeUSB Device/Network/Internal SATA burner
Network
Ethernet1 RJ-45 port (10/100/1000Mbps)
PoE8 ports (IEEE802.3af/at) for PoE model
Network FunctionHTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P
Max. User Access128 users
Smart PhoneiPhone, iPad, Android
Storage
Internal HDD2 SATA ports, up to 12TB
Auxiliary Interface
USB2 ports (1 Rear USB3.0,1 Front USB2.0)
RS2321 port, For PC communication&Keyboard
General
Power SupplySingle, DC12V/4A for non-PoE model
Single, AC 100~240V, 50/60 Hz for PoE model
Power ConsumptionNVR: 9.5 W for non-PoE model(without HDD)
15.2W for PoE model(without HDD)
PoE: Max 25.5W for single port, 130W in total
Working Environment-10°C~+55°C / 10%~90%RH / 86~106kpa
Dimension
(W×D×H)		1U, 375mm×282mm×56mm(non-PoE model)
375mm×327mm×53mm(PoE model)





 Dahua H.265 16ch NVR, Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)
