Original Dahua 1080P Wi-fi Kit KIT/NVR4104-W/2-HDBW1320E-W Dahua NVR Kit Easy Installation Plug&play

Original Dahua 1080P Wi-fi Kit KIT/NVR4104-W/2-HDBW1320E-W Dahua NVR Kit Easy Installation Plug&play thumbnail-1
Original Dahua 1080P Wi-fi Kit KIT/NVR4104-W/2-HDBW1320E-W Dahua NVR Kit Easy Installation Plug&play photo-1
US$ 1 - 150 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Dahua
Model Number:
KIT/NVR4104-W/2-HDBW1320E-W
Contact Supplier Request Quote Chat Now
Shenzhen Guowei Security Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Dahua
Model Number KIT/NVR4104-W/2-HDBW1320E-W





Features

>Easy installation, plug&play
>Support P2P, allowing easier home applications
>Support WPS, make easier connection
>H.264 dual-stream video compression
>HDMI/VGA simultaneous video output
>All channel 1080P recording
>Multiple network monitoring: web-browser, smart phone/tablet app



Model KIT/NVR4104-W/2-HFW1120S-W
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel
Two-way Talk 1 channel Input,1 channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression H.264/MJPEG
Resolution 1080P(1920×1080)/720P(1280×720)/D1 (704×576/704×480) & etc.
Record Rate 80Mbps
Bit Rate 48~8192kbps
Record Mode Manual, Schedule(Regular(Continuous), MD), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Playback & Backup
Sync Playback 1/4
Search Mode Time/Date, MD & Exact search (accurate to second), Smart search
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device/Network/Internal SATA burner
Network
Ethernet 1RJ-45 port (10/100Mbps)
Wireless Network Built-in Wifi module, 2 WiFi Antenna
Network Function HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P
Max User Access 128 users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD 1 SATA port, up to 4TB
Auxiliary Interface
USB 2 ports (1 Rear), USB2.0
General
Power Supply DC12V/2A
Power Consumption NVR: 10W (without HDD)
Working Environment -10°C~+55°C/10%~90%RH/86~106kpa
Camera
Image Sensor 1/3” 3Megapixel progressive scan CMOS
Effective Pixels 2048(H)x1536(V)
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3(4)~1/100000s
Min. Illumination Color: 0. 1Lux/F2.0;  0Lux/F2.0 (IR on)
S/N Ratio More than 50dB
Camera Features
Max. IR LEDs Length 30m
Day/Night Auto(ICR) / Color / B/W
Backlight Compensation BLC /HLC /DWDR
White Balance Auto/Manual
Gain Control Auto/Manual
Noise Reduction 3D
Privacy Masking Up to 4 areas
Lens
Focal Length 3.6/2.8mm lens optional
Max Aperture F2.0
Focus Control Manual
Angle of View H: 77°
Lens Type Fixed lens
Mount Type Board-in Type
Video
Compression H.264H/H.264B/H.264/ MJPEG
Resolution 3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/ VGA(640×480)/QVGA(320×240)
Frame Rate Main Stream :  3M(1 ~ 20fps)/1080P(1 ~ 25/30fps)
Sub Stream :  D1/CIF(1 ~ 25/30fps)
Bit Rate H.264: 32K ~ 8Mbps
Network
Ethernet RJ-45 (10/100Base-T)
Wi-Fi Range 50m(open field)
Protocol IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS
Wi-Fi Wi-Fi(802.11b/g)
Compatibility ONVIF, CGI
Max. User Access 20 users
Smart Phone iPhone, iPad, Android, Windows Phone
General
Power Supply DC12V
Power Consumption <5.5W(IR on)
Working Environment -30°C~+50°C, Less than 95%RH
Ingress Protection IP67
Vandal Resistance IK10
Carton
Dimension(W×D×H) 378*216*288 mm





Welcome to visit us!

1. Our office building:

2. We have our own factory with ISO certificate. And our own products can work well with dahua system.

A. Raw Materials

Raw Materials sourced from trusted suppliers. Main raw materials like sensor, chipset and lens, we source from Sony, Ti and Aptina...

B. Assembling

we have a perfect management system in conformity with 6S methodology in manufacturing management to ensure that factory is really safe and clean.

C. Aging Products

24 hours aging testing precedure avoid defects, and make sure excellent performance of our products.

D. OEM&ODM

Customer LOGO can be printed on goods/color box/labels upon confirmed.

E. Quality Test

Company invests abundant capital in advanced testing equipments to ensure products quality. Test including: Waterspray test, Constant temperature and moisture test, Transportation simulation test, Salt spray test, etc.
