Home > Products > Vibration test system > Electro Dynamic Vibration Shaker Test System With Slip Table
Electro Dynamic Vibration Shaker Test System With Slip Table
- 40 Set / Sets per Month
- ANY CHINESE MAIN PORT
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | ASLi | |
| Model Number | ES Seires | Power | Electronic | |
| Usage | Vibration Testing Machine |
Product Description
Electro Dynamic Vibration Shaker Test System With Slip Table
Electro Dynamic Vibration Shaker Test System / features:
1. Well-designed dynamic circle skeleton, with a higher stage axial resonance frequency.
2. Two-magnetic circuit, magnetic flux leakage low
4. Trunnion isolation foundation dedicated to hormone use, the installation of mobile convenience.
5. Advanced technology move around the system to ensure that the dynamic circle of high reliability.
6. New duct design and enhance the cooling effect.
7. Static stiffness, dynamic stiffness of the bearing small balloon
technical parameters:
Model | Rated Sine Force (N) | Rated Random Force (N) | Frequency Range (Hz) | Rated Acceleration (m/s2) | Rated Speed(m/s) | Rated Displacement (p-p)mm | Max. Loading (Kg) | moving coil(Kg) | Dimension of Moving coil(mm) |
ES-1 | 1000 | 1000 | 3-3500 | 400 | 1.2 | 25 | 70 | 2.5 | Φ150 |
ES-2 | 2000 | 2000 | 3-3500 | 800 | 1.6 | 25 | 70 | 2.5 | Φ150 |
ES-2a | 2000 | 2000 | 3-3500 | 300 | 1.6 | 40 | 70 | 8 | Φ230 |
ES-3 | 3000 | 3000 | 3-3500 | 1000 | 1.6 | 25 | 100 | 3.5 | Φ150 |
ES-3a | 3000 | 3000 | 3-3500 | 400 | 1.6 | 40 | 120 | 9 | Φ230 |
..... | |||||||||
ES-200 | 200000 | 200000 | 3-2000 | 1000 | 1.8 | 51 | 2500 | 200 | Φ650 |
ES-350 | 350000 | 350000 | 3-1700 | 1000 | 1.8 | 51 | 4500 | 300 | Φ870 |
Vibration Shaker Test System With Slip Table / horizontal platforms:
Model | Bench Size (mm) | Frequency Range (Hz) | Weight of Moving Parts (kg) |
LT0303 | 300×300×22 | 5-1000 | 6.6 |
.... | |||
LT 1212 | 1200× 1200×30 | 5-800 | 126 |
vertical expanders:
Model | Weight (kg) | Max. Frequency (Hz) | Bench Size (mm) |
VT300 | 10 | 2000 | Φ300 |
VT400 | 16 | 2000 | Φ400 |
.... | |||
VT1212 (Round bench) | 220 | 350 | Φ1200 |
Electro Dynamic Vibration Shaker Test System With Slip Table
