Help CenterOnvif Intelligent Analysis Face Detect 16 Ports PoE NVR 32ch
Related Products
-
Original 2016 Dahua 32CH 1.5U 4K H.265 Network Video Recorder,NVR5432-16p-4KS2 Support IP66,P2PUS$ 1 - 400MOQ: 1 Piece -
GWSECU KD-Z4808NH/16NH/32NH 8/16/32 Channel 2U Network Video Recorder Quality ChoiceUS$ 250 - 350MOQ: 1 Piece
-
GWSECU KD-Z3508NH/Z3516NH/Z3532NH8/16/32 Channel 1U Network Video RecorderUS$ 100 - 150MOQ: 1 Piece
-
GWSECU KD-Z3508/16/32NH-8P8/16/32 Channel 1U 8POE Network Video RecorderUS$ 50 - 80MOQ: 1 Piece
-
Embedded LINUX H.265 4K NVR 64ch 8 SATA III Ports, up to 48TB Powerful Dahua NvrUS$ 1 - 900MOQ: 1 Set
GWSecu had passed ISO9001 quality management system authentication and all products have been successfully certificated by CE, FCC, ROHS.
We have online English technician team to support customers!
We're reliable CCTV manufacturer started 2001.
GWSecu Camera Special heat-dissipate structure:
(Enabled cameras 7*24 stable performance)
H.264/MJPEG-4 dual codec decoding
Up to 16/32 channel IP camera input
128/200Mbps incoming bandwidth
All channel synchronous playback
1 CH face detection or 2 CH perimeter detection(except 32ch)
HDMI /VGA/ CVBS simultaneous video output
ONVIF Version 2.4 conformance
Support 2 SATA HDD no limited, 2 USB2.0
Support IPC UPnP, 16PoE ports
Support P2P cloud storage, QR code
Support multiple languages, max. 28 languages
Multiple network monitoring: Web viewer, CMS
| Model | KD- Z3516NH-16P | KD- Z3532NH-16P |
| Special function | ||
| P2P function | Using Device ID and password to remote monitoring playback and control. |
|
| Cloud Storage | Support Dropbox and Google Drive. | |
| System | ||
| Operating System | embedded LINUX | |
| Basic function | Live monitoring recording playback backup & remote access | |
| Control Mode | USB mouse Network | |
| Video | ||
| Video Input | 16 channel | 32 channel |
| Incoming Bandwidth | 128Mbps | 200Mbps |
| Output bandwidth | 128Mbps | 160Mbps |
| Video Output | 1 CVBS BNC (1.0Vp-p75ohms) | |
| 1 VGA 1920×1080 1280×1024 1280×720 1024×768 | ||
| 1 HDMI 1920×1080 1280×1024 1280×720 1024×768 | ||
| Support Protocol | ONVIF2.4 GWSECU | |
| Standard | PAL / NTSC | |
| Audio | ||
| Input | 1CHRCA(Line in2Vpp1Kohms) | |
| Output | 1CHBNC(Line out2Vpp300ohms) | |
| Two-way Talk | Support | |
| Audio Compression | G.711A | |
| Audio Bit Rate | 64Kbps | |
| Display | ||
| IP Resolution | Main stream: max. 1920x2048 ; Auxiliary stream: D1 | |
| Resolution | 5MP/3MP/1920×1080 1280×1024 1280×720 1024×768 | |
| Display Split | 1/4/8/9/16 |
1/4/8/9/ 16/25/32 |
| Privacy Masking | Four zones for privacy masking for each channel | |
| Recording | ||
| Video Compression | MPEG-4/H.264(High Profile Level4.2) | |
| Image Encoding | Adjustable encoding quality variable code stream/fixed code stream | |
| Dual Stream | Support | |
| Record Mode | Manual Auto(schedule) motion detection stop | |
| Time bar | Support | |
| Video Detection | ||
| Trigger Events | Recording Tour Video Push Email FTP Buzzer & Screen tips | |
| Video Detection | 396 (22×18) detection zone variable sensitivity levels | |
| Capture | JPEG capture | |
| Intelligent Analysis |
1 CH.Face detection or 2 CH. Perimeter detection support 1080P |
N/A |
| Playback & Backup | ||
| Synchronous Playback | 16 Channel | |
| Playback Performance | 13CH 720P 30fps or 6CH 1080P 30fps | |
| Backup Mode | USB HDD Network Backup | |
| Network | ||
| Ethernet | RJ-45port (10/100/1000Mbps) | |
| Network Function | HTTP TCP/IP UPNP RTSP UDP SMTP DHCP PPPOE DDNS SNTP FTPP2P | |
| Remote Operation |
Monitoring PTZ control playback system setting file download log information |
|
| Smart Phone Monitoring | iPhone iPad Android | |
| Storage | ||
| Internal HDD | 2 SATA ports HDD capacity no limited | |
| HDD Management | Hard disk hibernation technology HDD faulty alarm | |
| Auxiliary Interface | ||
| USB | 2 ports USB2.0 | |
| General | ||
| Power Supply | 110V~220V±10% ±10% 47Hz~63Hz | |
| POE | 16 CH IEEE 802.3af | |
| Power Consumption | 10W(without HDD PoE) | |
| Working Environment | -10°C~+55°C /10%~90%RH | |
| Weight | 3KG (without HDD) | |
| Dimension(L×W×H) | 1U 360x311.5x48mm | |
| Package | 405x365x123mm | |
We provide GWSECU private housing hd IP and AHD/CVI/TVI cameras, using exquisite metal housing with powder injection, latest IR Array lights with more efficiency and longer lifespan.
Part of our new products and housing as below:
| |
|
|
| 5Mp 30fps Sony WDR bullet | 5Mp 120db WDR Sony Box camera | 3Mp Motorized lens Bullet Camera |
| |
|
|
| 2Mp Speed Dome PTZ IP Camera | 16 ports PoE NVR with face detection |
Star Light HD-CVI Camera with color night view |
Part of GWSecu Camera Housing:
(All our private housing apply to IP Camer and AHD/CVI/TVI Cameras)
All our cameras and DVR/NVRs with online video demostration, and video recording. We would very love to share with you if interesting.
Mobile APP: Support 16ch maximum:
About us
Shenzhen Guowei Security Co., ltd is a national high - tech enterprise that integrates the design, development, production and sales of network video surveillance products.
GWSecu has a professional and experienced R&D team that well knows core technologies, pursuing products with reliability, complement and compatibility. To guarantee stable performance, GWSecu has strict control on design, raw material and processing of its products.
As a member of Onvif, Its IP Camera and NVR series have passed international ONVIF Profile S standards, perfectly compatible with China’s mainstream storage device suppliers (like Dahua, Hikvision etc.) and international platform (Milestone, Digifort etc.).
GWSecu Factory Show:
As an ISO certified professional HD IP CCTV Camera Manufacturer in China, "Quality First" was our principle. All GWSECU private housing cameras using our special heat-dissipate structure design, making sure all items with stable performance.
A: Raw Materials
Raw Materials sourced from trusted suppliers. Main raw materials like sensor, chipset, lens and infrared lights. We source from Sony, Ti and Aptina directly.
B: Assembling
As ISO factory, we have a perfect management system in conformity with 6S in manufacturing
management to ensure that factory is really safe and clean.
We also have all kinds of production and inspection equipment to maximize high-efficient production capacity while ensuring product quality.
C: Quality Test
GWSecu invests abundant capital in advanced testing equipments to ensure products quality.
Test including: Waterspray test, Constant temperature and moisture test, Transportation simulation test,
Salt spray test.
D: OEM & ODM
Customer LOGO can be printed on goods/color box/labels upon confirmed.
We attend worldwide exhibitions in Dubai, Las Vegas, Moscow, London, Germany, Thailand, South Africa. "Honest" and "Sincerity" is the principle we serve the customers.
We provide 2 years warranty service for all products.
OEM service: Silk-print with brand, IE Browser Login, WEB GUI page, local CMS software with customize brand.
FAQ.
1. Payment
What are the terms of payments you offer?
We accept payment via T/T, Paypal, Westunion etc
2. Shipment
How long will it takes to deliver goods?
We will deliver your goods within 7-10 working days after an order confirmed
3. What kind of packaging you offer?
We will pack the goods well with exporting packages and bubble wrap to make sure all goods in a good condition during storage and delivery.
4. What kind of transportation methods you offer?
A. We usually use express delivery like DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies.
B. We also can deliver your goods by air and sea as your request.
Shenzhen GuoWei Security Co .,Ltd
CCTV Security manufacturer since 2001 / Focus on IP Security System for 8 years / ISO certificate factory
Head Office: 6/F, Dong Fang Building, No.16 Gaoxin North 6th Road, North High-tech Park, Nanshan District, Shenzhen
Factory Add: 4/F, Jinma Building, Shihuan Rd, Shilongzai Community, Shiyan, Baoan District, Shenzhen, China
