Xenon Accelerated Weathering Meter/Climatic Test Chamber

Xenon Accelerated Weathering Meter/Climatic Test Chamber photo-1
US$ 5,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ASLi
Model Number:
XL - 1000
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/HongKong
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name ASLi
Model Number XL - 1000
Power Electronic
Usage Universal Testing Machine

 Xenon Accelerated Weathering Meter/Climatic Test Chamber Application:

Xenon Accelerated Weathering Meter/Climatic Test Chamber is a comprehensive climate testing machine,

it can do climatic aging test, and also can do fading acceleration test under color effect or color changed. The test range

 including: dying and finishing, printing, leather, plastic, plyglass, painting, textile, printing ink, rubber and also the industry

 relative color.  Light fastness and fade grade can be known in short time. Those materials exposed at simulated

sunlight to evaluated the material's light fastness performance. To simulate and strengthen the test according to light

energy, temperature, rain fall or condensation, humidity, .etc these main climate factors. Adopt simulated sunlight

spectrum’xenon arc light to create destructive waves under different environment. It can be used for choosing new

materials, improving existing materials, or assessment of durability change after material composed.



 Xenon Accelerated Weathering Meter/Climatic Test Chamber Features:

1. Advanced design technology and concept,

2. Excellent technology of producing and outstanding system of quality management,

3. Xenon lamp tester can be the most realistic simulated solar spectrum, including ultraviolet,

visible and infrared.

4. Be tested in the range of the full spectrum, necessary for most textile sun and color fastness test.

5. To determine the color fastness and aging to sunlight, weather resistance, etc.



Xenon Accelerated Weathering Meter/Climatic Test Chamber Technical Parameters:

Model

XL - 1000

Internal Dimension

 WxHxD (mm)

1000x1000x1000



External Dimension



WxHxD (mm)

1500x2000x1400



Tube Using Life (H)

1500

Tube Power

1KW/6KW

Illumination  Intensity

340nm

0.35~0.6w/m2

420nm

0.8~3.5w/m2

300~400nm

48~60w/m2

300~800nm

520~800w/m2

300~1000nm

575~1000w/m2

Full spectrum

1200±200w/m2

Lighting Filter Type

Inner filter

Borosilicate

Infrared adsorbing

Borosilicate

Infrared adsorbing

Quartz

Outer filter

Borosilicate

Quartz

Soda lime

Infrared adsorbing

Quartz

Simulated Test Status



Test samples;

Explore under sunlight

Test samples;

Explore under

sunlight(Below

300~1000nm)

Test samples:

Explore under

sunlight through

glass window

Test samples:

Explore under

sunlight through

glass window(Below 300~1000nm)



Test samples:

Explore under

outer space

Cooling System

Water cooling or wind cooling

Temperature Control

Range of the Test

Cabinet

Black panel temperature BPT 40~120ºC(±3ºC)

Black standard temperature :BST 38~120ºC(±3ºC)

Humidity Control

Range of the Test

Cabinet

Humidity when lighting: 20%R.H.~75%R.H. (± 5%R.H.)

Humidity when dark: 60%R.H.~95%R.H. (± 5%R.H.)

Rotating Speed of the

Samples Holder(RPM)

1~5 adjustable

Diameter of Sample

Shelf(mm)

500±50

Sunlight Exposure

Cycle

0.01~999 hours 59mins

Raining Period

/ Time

Raining Period:1~240mins,discontinuous-type, adjustable

Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa

Spray water flow(L/min)

1~2.4

Explore Area(cm2)

7500

Power

 AC 380 V(±10%),50/60HZ ,3ø5 Lines







Xenon Accelerated Weathering Meter/Climatic Test ChamberXenon Accelerated Weathering Meter/Climatic Test Chamber
