SD22204T-GN-W
2 Megapixel WIFI Full HD Network Mini High Speed PTZ Dome Camera
Features:
4x optical zoom
H.264 & MJPEG Triple-streams encoding
Max. 25/30fps@1080P(1920x1080) & 50/60fps@720P resolution
WDR, Day/Night(ICR), Ultra DNR, Auto iris, Auto focus
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Max 100°/s pan speed
Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
Support intelligent 3D positioning with DH-SD protocol
Micro SD memory, POE
| Model | DH-SD22204T-GN-W | |
| Camera | ||
| Image Sensor | 1/2.7” CMOS | |
| Effective Pixels | 1920(H) x 1080(V), 2Megapixels | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | 1/1 ~ 1/30,000s | |
| Min. Illumination | Color: 0.05Lux F1.6; B/W: 0.005Lux F1.6 | |
| S/N Ratio | More than 55dB | |
| Camera Features | ||
| Day/Night | Auto(ICR) / Color / B/W | |
| Backlight Compensation | BLC / HLC / WDR | |
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | |
| Gain Control | Auto / Manual | |
| Noise Reduction | Ultra DNR (2D/3D) | |
| Privacy Masking | Up to 24 areas | |
| Digital Zoom | 16x | |
| Lens | ||
| Focal Length | 2.7mm~11mm(4x Optical zoom) | |
| Max Aperture | N/A | |
| Focus Control | Auto / Manual | |
| FOV-H | H: 112.5° ~ 30° | |
| Close Focus Distance | 100mm~ 1000mm | |
| PTZ | ||
| Pan/Tilt Range | Pan: 0° ~ 355°; Tilt: 0° ~ 90°, auto flip 180° | |
| Manual Control Speed | Pan: 0.1° ~100° /s; Tilt: 0.1° ~60° /s | |
| Preset Speed | Pan: 100° /s; Tilt: 60° /s | |
| Preset | 300 | |
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan | |
| Speed Setup | Human-oriented focal length/ speed adaptation | |
| Power up Action | Auto restore to previous PTZ and lens status after power failure | |
| Idle Motion | Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period | |
| Video | ||
| Compression | H.264 / MJPEG | |
| Resolution | 1080P(1920×1080)/ 720P(1280×720) / D1(704×576/ 704×480) /CIF | |
| (352×288/352×240) | ||
| Frame Rate | Main Stream | 1080P/ D1 (1 ~ 25/30fps), 720P(1~50/60fps) |
| Sub Stream 1 | D1/CIF(1 ~ 25/30fps) | |
| Sub Stream 2 | 720P/ D1/ CIF (1 ~ 25/30fps) | |
| Bit Rate | H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps | |
| Intelligent Function | ||
| IVS (optional) | Tripwire, Intrusion, Abandoned Object Detection, Missing Object Detection, | |
| Face Detection | Support | |
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| WIFI | Support | |
| Protocol | IPv4/ IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x | |
| ONVIF | ONVIF Profile S | |
| Max. User Access | 20 users | |
| Smart Phone | iPhone, iPad, Android, Windows Phone | |
| Auxiliary Interface | ||
| Memory Slot | Micro SD, Max 128GB | |
| General | ||
| Power Supply | DC12V | |
| Power Consumption | 10W | |
| Working Environment | -30ºC ~ 60ºC / Less than 90% RH | |
| Ingress Protection | IP66 & IK10 | |
| Dimensions | Φ122 (mm) x 89 (mm) | |
| Weight | 0.6kg | |
We provide GWSECU private housing hd IP and AHD/CVI/TVI cameras, using exquisite metal housing with powder injection, latest IR Array lights with more efficiency and longer lifespan.
Part of our new products and housing as below:
| |
|
|
| 5Mp 30fps Sony WDR bullet | 5Mp 120db WDR Sony Box camera | 3Mp Motorized lens Bullet Camera |
| |
|
|
| 2Mp Speed Dome PTZ IP Camera | 16 ports PoE NVR with face detection |
Star Light HD-CVI Camera with color night view |
Part of GWSecu Camera Housing:
(All our private housing apply to IP Camer and AHD/CVI/TVI Cameras)
All our cameras and DVR/NVRs with online video demostration, and video recording. We would very love to share with you if interesting.
Mobile APP: Support 16ch maximum:
About us
Shenzhen Guowei Security Co., ltd is a national high - tech enterprise that integrates the design, development, production and sales of network video surveillance products.
GWSecu has a professional and experienced R&D team that well knows core technologies, pursuing products with reliability, complement and compatibility. To guarantee stable performance, GWSecu has strict control on design, raw material and processing of its products.
As a member of Onvif, Its IP Camera and NVR series have passed international ONVIF Profile S standards, perfectly compatible with China’s mainstream storage device suppliers (like Dahua, Hikvision etc.) and international platform (Milestone, Digifort etc.).
GWSecu Factory Show:
As an ISO certified professional HD IP CCTV Camera Manufacturer in China, "Quality First" was our principle. All GWSECU private housing cameras using our special heat-dissipate structure design, making sure all items with stable performance.
A: Raw Materials
Raw Materials sourced from trusted suppliers. Main raw materials like sensor, chipset, lens and infrared lights. We source from Sony, Ti and Aptina directly.
B: Assembling
As ISO factory, we have a perfect management system in conformity with 6S in manufacturing
management to ensure that factory is really safe and clean.
We also have all kinds of production and inspection equipment to maximize high-efficient production capacity while ensuring product quality.
C: Quality Test
GWSecu invests abundant capital in advanced testing equipments to ensure products quality.
Test including: Waterspray test, Constant temperature and moisture test, Transportation simulation test,
Salt spray test.
D: OEM & ODM
Customer LOGO can be printed on goods/color box/labels upon confirmed.
We attend worldwide exhibitions in Dubai, Las Vegas, Moscow, London, Germany, Thailand, South Africa. "Honest" and "Sincerity" is the principle we serve the customers.
We provide 2 years warranty service for all products.
OEM service: Silk-print with brand, IE Browser Login, WEB GUI page, local CMS software with customize brand.
FAQ.
1. Payment
What are the terms of payments you offer?
We accept payment via T/T, Paypal, Westunion etc
2. Shipment
How long will it takes to deliver goods?
We will deliver your goods within 7-10 working days after an order confirmed
3. What kind of packaging you offer?
We will pack the goods well with exporting packages and bubble wrap to make sure all goods in a good condition during storage and delivery.
4. What kind of transportation methods you offer?
A. We usually use express delivery like DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies.
B. We also can deliver your goods by air and sea as your request.
Shenzhen GuoWei Security Co .,Ltd
CCTV Security manufacturer since 2001 / Focus on IP Security System for 8 years / ISO certificate factory
Head Office: 6/F, Dong Fang Building, No.16 Gaoxin North 6th Road, North High-tech Park, Nanshan District, Shenzhen
Factory Add: 4/F, Jinma Building, Shihuan Rd, Shilongzai Community, Shiyan, Baoan District, Shenzhen, China
