Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > 5.0Mp P2P IP CCTV Camera

5.0Mp P2P IP CCTV Camera

Name: 5.0Mp P2P IP CCTV Camera
Brand: GWSECU
SKU: 110177339
Availability: InStock

US$ 90 - 120 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

GWSECU

Model Number:

KDT-HD55AC85-P

Contact Supplier Request Quote Chat Now

Shenzhen Guowei Security Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name GWSECU

Model Number KDT-HD55AC85-P

Type IP Camera

Style Dome Camera

Sensor CMOS

Technology NetWork

Special Features Vandal-proof

Why Choose us?

2016 New Products


2.0mp Bullet IP Camera	2.0mp Dome IP Camera	2.0 Bullet IP Camera

1.3mp Dome Network Camera	H.265 2.0MP Network Camera	3.0MP Network Camera

Features:

>1/2.5” 5.0 Megapixel Progressive Scan Aptina CMOS sensor
>DaVinci High Performance DSP of TI
>H.264&MJPEG video compression and JPEG image capture
>Max 10fps @ 5.0MP (2592×1920)
>Dual encoding streams supported
>Varifocal lens 3.3-10.5mm/F1.4
>Built-in 1/1 alarm in/out
>Max IR Distance :30m
>True Day/Night ICR
>Micro SD memory, IK10, PoE
>Built-in Web server, NVR, CMS,APP
>IP66 all-environments protection

Specification:

Model			KDT-HD55AC85-P
General
processor	DaVinci High Performance DSP of TI
Operating System	embedded LINUX
Resource	Simultaneous remote monitoring local recording and remote control
User Interface	WEB CMS NVR APP
Camera
Image Sensor			1/2.5" 5.0 Megapixel Progressive Scan Aptina CMOS Sensor
Effective Pixels			2592 (H)×1920(V)
Electronic Shutter			1/5s to 1/50000s
Mini. Illumination			Color:0.6Lux/F1.2; B/W:0.08Lux/F1.2;0Lux/F1.2(IR on)
Signal Noise Ratio			>50dB
Day/Night Mode			Auto dual IR-Cut filter
Gain Control			Auto/Manual
White Balance			Auto/Manual
WDR Dynamic Range			DWDR
Lens			Varifocal lens 3.3-10.5mm/F1.4
Max IR Distance			30m
Video
Video Compression			H.264/MJPEG Optional
H.264 Encode Type			H.264 baseline/H.264 Main Profile/H.264 High Profile Optional
Video Bit Rate			Main Stream:200Kbps~12Mbps Sub Stream:100Kbps~6Mbps
Image Resolution			5.0Mp(2592 × 1920)/3.0Mp(2048 × 1536 )/1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480)
Encoding Speed			Main Stream: 5.0Mp /10fps;3.0Mp /20 fps ;1080P/720P(1~25fps/30fps)
			Extra Stream: D1/CIF:(1~25fps/30fps)
Video Format			PAL/NTSC
Audio
Audio Compression			G.711a/G.711u/RAW_PCM Optional
Audio Bit Rate			G.711a(8kbps)/G.711u(8kbps)/RAW_PCM(16kbps)
Audio Input			1-channel 3.5mm audio interface MIC IN/Line IN
Audio Output			1-channel 3.5mm audio interface (line level600Ω)
Network
Ethernet			RJ-45 (10/100base-T)
Network Protocol			IPv4/IPv6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPoE,SMTP
ONVIF			ONVIF Ver.2.4
Max User Access			10 users
Smart phone			Iphone Ipad Android
Remote Operation			Monitor Playback System setting File download Log information Maintenance & Upgrade
Auxiliary Interface
Reset Input		One Reset Button(Be effective after continues to hold down for 3 seconds)
Memory Slot		TF Card Max 64GB
RS485		PTZ Control
Alarm Input		1-channel input Normally Open/Normally Close modes adjustable
Alarm Output		1-channel output 120VAC 1A/24VDC 1A
Video Output		1Vp-p Composite Output(75Ω/BNC)
Environmental
Power Supply			DC12V
Power Consumption			<10W
Max IR Distance			30m
PoE			IEEE802.3af
Ingress Protection			IP66 only with External metal bracket
Dimensions(mm)			154×121.5mm
Weight(kg)			0.8Kg
Operating Environment			-40ºC ~ +60ºC Humidity less than95%(Non-condensing)

Demo

CMS&VSS Interface:

Web Interface:

Mobile Phone View:

GWSECU since 2001

Factory Shows

World-wide Clients

FAQ

We provide 2 years warranty service for all products.

OEM service: Silk-print with brand, IE Browser Login, WEB GUI page, local CMS software with customize brand.

1. Payment
What are the terms of payments you offer?
We accept payment via T/T, Paypal, Westunion,L/C at sight or Alipay via Alibaba

2. Shipment
How long will it takes to deliver goods?
We will deliver your goods within 7-10 working days after an order confirmed

3. What kind of packaging you offer?
We will pack the goods well with exporting packages and bubble wrap to make sure all goods in a good condition during storage and delivery.

4. What kind of transportation methods you offer?
A. We usually choose the cheapest express delivery for our clients, such as DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies.You could use your own forwarder if possible.
B. We also can deliver your goods by air and sea as your request.
