Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > New IP Camera CCTV Camera P2P
New IP Camera CCTV Camera P2P
US$ 50 - 90
MOQ: 8 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GWSECU
Model Number:
KDT-HD58AC83-P
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Nightvision IR Webcam Web CCTV CameraUS$ 60 - 90MOQ: 1 Piece -
ip Camera 2mp 30m ir 1080p Cctv CameraUS$ 50 - 70MOQ: 8 Pieces
-
Low Cost ip Camera Cctv CameraUS$ 1 - 20MOQ: 1 Piece
-
2MP ip Camera Brand Full hd Cctv CameraUS$ 40 - 80MOQ: 1 Piece
-
POE Dome Network Camera 3MP IR IP Camera CCTV Camera With Motorized LensUS$ 80 - 120MOQ: 8 Pieces
Place of Origin
Guangdong, China
Brand Name
GWSECU
Model Number
KDT-HD58AC83-P
Type
IP Camera
Style
Dome Camera
Sensor
CMOS
Technology
NetWork
Special Features
Vandal-proof
3.0Mp HD 2.8~12mm Water-Proof & Vandal-Proof IR Network Dome Camera
Why Choose us?
2016 New Products
|
|
|
| 2.0mp Bullet IP Camera | 2.0mp Dome IP Camera | 2.0 Bullet IP Camera |
|
|
|
| 1.3mp Dome Network Camera | H.265 2.0MP Network Camera | 3.0MP Network Camera |
Features:
>1/3" 3.0 Megapixel Progressive Scan Aptina CMOS sensor
>Ti DaVinci Series DSP
>H.264 & MJPEG dual-stream encoding
>Max 20fps @ 3.0MP (2048×1536)
>Dual encoding streams supported
>2.8~12mm /F1.4 Manual lens
>Built-in 1/1 alarm in/out
>Max IR Distance :30m
>True Day/Night ICR
>Micro SD memory, IK10, PoE
>Built-in Web server, NVR, CMS,APP
>Ti DaVinci Series DSP
>H.264 & MJPEG dual-stream encoding
>Max 20fps @ 3.0MP (2048×1536)
>Dual encoding streams supported
>2.8~12mm /F1.4 Manual lens
>Built-in 1/1 alarm in/out
>Max IR Distance :30m
>True Day/Night ICR
>Micro SD memory, IK10, PoE
>Built-in Web server, NVR, CMS,APP
Specification:
| Model | KDT-HD58AC83-P |
| General | |
| Main Processor | DaVinci High Performance DSP of TI |
| Operating System | embedded LINUX |
| Resource | Simultaneous remote monitoring local recording and remote control |
| User Interface | WEB CMS NVR APP |
| Camera | |
| Image Sensor | 1/3" 3.0Megapixel Progressive Scan Aptina CMOS Sensor |
| Effective Pixels | 2048(H)×1536(V) |
| Electronic Shutter | 1/5s to 1/50000s |
| Mini. Illumination | Color:0.2Lux/F1.2; B/W:0.01Lux/F1.2; 0Lux/F1.2(IR on) |
| Signal Noise Ratio | >50dB |
| Day/Night Mode | Auto dual IR-Cut filter |
| Gain Control | Auto/Manual |
| White Balance | Auto/Manual |
| WDR Dynamic Range | DWDR |
| Lens | 2.8mm~12mm/F1.4 Manual lens |
| Max IR Distance | 20m |
| Video | |
| Video Compression | H.264/MJPEG Optional |
| H.264 Encode Type | H.264 baseline/H.264 Main Profile/H.264 High Profile Optional |
| Video Bit Rate | Main Stream: 200bps~12Mbps |
| Sub Stream: 100Kbps~6Mbps | |
| Image Resolution | 3.0Mp(2048×1536 )/1080P(1920×1020) / 720P(1280×720) |
| Encoding Speed | Main Stream: max 3.0Mp /20 fps(PAL) ;max 3.0Mp /20 fps(NTSC) |
| Extra Stream: max D1 /25 fps(PAL) ;max D1 /30 fps(NTSC) | |
| Video Format | PAL/NTSC |
| Audio | |
| Audio Compression | G.711a/G.711u/RAW_PCM Optional |
| Audio Bit Rate | G.711a(8kbps)/G.711u(8kbps)/RAW_PCM(16kbps) |
| Audio Input | 1-channel 3.5mm audio interface MIC IN/Line IN |
| Audio Output | 1-channel 3.5mm audio interface (line level600Ω) |
| Network | |
| Ethernet | RJ-45 (10/100base-T) |
| Network Protocol | IPv4/IPv6 RTSP/RTP/RTCP TCP/UDP HTTP DHCP DNS FTP DDNS PPPoE SMTP |
| ONVIF | ONVIF Ver.2.4 |
| Max User Access | 10 users |
| Smart phone | Iphone Ipad Android |
| Remote Operation | Monitor Playback System setting File download Log information Maintenance & Upgrade |
| Auxiliary Interface | |
| Reset Input | One Reset Button(Be effective after continues to hold down for 3 seconds) |
| Memory Slot | TF Card Max 64GB |
| RS485 | PTZ Control |
| Alarm Input | 1-channel input Normally Open/Normally Close modes adjustable |
| Alarm Output | 1-channel output 120VAC 1A/24VDC 1A |
| Video Output | 1Vp-p Composite Output(75Ω/BNC) |
| Environmental | |
| Power Supply | DC12V |
| Power Consumption | <10W |
| Working Environment | -40ºC ~ +60ºC Humidity less than95%(Non-condensing) |
| Max IR Distance | 20m |
| Protection Level | IP66 |
| PoE | IEEE802.3af |
Demo
CMS&VSS Interface:
Web Interface:
Mobile Phone View:
GWSECU since 2001
Factory Shows
World-wide Clients
Contact us
FAQ
We provide 2 years warranty service for all products.
OEM service: Silk-print with brand, IE Browser Login, WEB GUI page, local CMS software with customize brand.
1. Payment
What are the terms of payments you offer?
We accept payment via T/T, Paypal, Westunion,L/C at sight or Alipay via Alibaba
2. Shipment
How long will it takes to deliver goods?
We will deliver your goods within 7-10 working days after an order confirmed
3. What kind of packaging you offer?
We will pack the goods well with exporting packages and bubble wrap to make sure all goods in a good condition during storage and delivery.
4. What kind of transportation methods you offer?
A. We usually choose the cheapest express delivery for our clients, such as DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies.You could use your own forwarder if possible.
B. We also can deliver your goods by air and sea as your request.
