IPX3/IPX4 Waterproof Test Chamber
ASLI , as a leading IPX3/IPX4 waterproof test chamber supplier from china, has more than 25 year’s experience in IPX3/IPX4 waterproof test chamber manufacture. ASLI boost his own technical team in IPX3/IPX4 waterproof test chamber R&D, and it also introduces the advance quality control method in IPX3/IPX4 waterproof test chamber production. Our IPX3/IPX4 waterproof test chamber series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
IPX3/IPX4 Waterproof Test Chamber Technical Parameters :
Model |
RT-1000A |
RT-1000B |
Test Standard |
JIS, ISO, IEC60529, DIN40050, GB2423, GB4208 standard |
|
Internal Dimension WxHxD (mm) |
1000x1000x1000 |
|
External Dimension WxHxD (mm) |
1600x1900x1400 |
|
JIS Test |
Flow:1.8L/Min~3.9L/Min |
Flow:24.5L/Min~39.2L/Min |
pressure:0.1kgf/cm2~0.3 kgf/cm2 |
pressure: 1kgf/cm2~3 kgf/cm2 |
|
Drop Test |
1~1.5mm/Min Adjustable IPx1 IPx2 drop speed: 1~1.5mm/Min adjustable |
3~3.5mm/Min Adjustable drop speed:3~3.5mm/ Min adjustable
|
Rain of Pipe-Swing Test |
IPx3 IPx4 swing pipe: RT~±80°C Flow:0.07L/min per Nozzle |
|
Water Spray Test |
IPx3 IPx4 jet:2.5m~3m
flow :12.5L/min ~100L/Min |
|
High Pressure Jet Test |
80Kgf~100Kgf IPx9K pressure of jet:80Kgf~100Kgf Flow:14~16L/Min |
|
Rotating Speed of Rotating-Plate |
4~20 RPM adjustable |
|
IPX3/IPX4 Waterproof Test Chamber Features :
1. Water pressure and flow rate adjustable.
2. Unique sprinkler can stably control the rain quantity and pressure.
3. This equipment (Model B) can make the test products’ temperature rising from RT-85°C
4. Inner case’s material is imported steel plates, Shell is made of #304 stainless steel.
5. This equipment applies rain spray test for products and parts.
IPX3/IPX4 Waterproof Test Chamber Application :
It is widely applied to electrical and electronic products, lamps and lanterns, electrical cabinet, electrical components, automobile, motorcycle and its spare parts and other products. It provides the basis to improve the performance of the products.
Use the table below to find products that comply with a specific IP Code test:
All Products (IP Code Testing) | ||
X1 |
Protection against vertically dripping water |
|
X2 |
Dripping water ± 15° from vertical |
|
X3 |
Protection against spraying water |
|
X4 |
Protection against splashing water |
|
X5 |
Protection against low pressure jetting water |
|
X6 |
Protection against high pressure jetting water |
|
X6K |
Extremely high pressure jetting water |
|
More information about waterproof testing equipment ,please contact Asli sales person they will give you more detailed advices !
More Pictures for reference:
...
