Constant Temperature Humidity Tester/ Constant Climate Chambers/ Constant Environment Chamber / Temperature &Humidity Chambers
Constant Temperature Humidity Test Machine Features
1.This temperature and humidity test chabmer with graceful appearance, circularly shaped body, surface treated
with mist strips, and plane handle with no reaction. Easy to operate, safe and reliable.
2. Rectangular doubleglassed watching window for the observation of the test production during the testing process.
The window is equipped with sweat-proof electrical heating device that can prevent water steam from condensing
into droplets,and with high brightness
PL fluorescent bulbs to provide light inside the box.
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and
automatically recyclable.
Constant Temperature Humidity Test Machine Application:
Temperature and humidity test chamber is used to test various types of materials for their tolerances of heat, cold,
dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance,and products
from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aero
space industries.
Constant Temperature Humidity Test Machine Technical Parameters :
Model |
F-TH-150(A~F) |
F-TH-225(A~F) |
F-TH-408(A~F) |
F-TH-800(A~F) |
F-TH-1000(A~F) |
Internal Dimension WxHxD( mm) |
500x600x500 |
600x750x500 |
600x850x800 |
1000x1000x800 |
1000x1000x1000 |
Internal Dimension WxHxD (mm) |
1100x1750x1600 |
1200x1800x1700 |
1250x1900x1900 |
1600x2050x2150 |
1700x2200x2300 |
|
Range of Fast Temperature Change |
Temperature Range: -70~+150°C; Range of Fast Temperature Change: -45~+85°C; Max. temperature rising/falling speed is 15°C/min when the whole process with linear control . |
||||
Humidity Range(Optional) |
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional ,need Dehumidifier) |
||||
|
Indication resolution/ Distribution Uniformity of Temperature and Humidity |
0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H. |
||||
|
Control Accuracy of Temperature and Humidity |
±0.5°C; ±2.5% R.H. |
||||
|
Temperature Rising/ Falling Velocity |
Rising/Falling Speed Rate with linear control : 3~15°C/min, adjustable Rising/Falling Speed Rate non-linear control : 3~30°C/min, adjustable |
||||
Material |
Interior material is SUS 304# stainless steel,exterior is stainless steel or SEE cold-rolled steel with paint coated. |
||||
Insulation Material |
Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
||||
Cooling System |
Water cooled/single segment compressor |
||||
Protection Devices |
Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection |
||||
Optional Accessories |
Inner door with operation hole(Optional), Water Purifier, Dehumidifier |
||||
Compressor |
French Tecumseh Brand, Germany Bizer Brand |
||||
Power |
AC380V 3 Phase 5 lines, 50/60HZ |
||||
Approx. Weight(Kg) |
250 |
350 |
450 |
600 |
700 |
Warranty: one year free warranty for whole set machine,lifelong time maintainance.
After-sale service: feedback within 2 hours after get the call.
Constant Temperature Humidity Test Machine Pictures :
...
