I.p. Camera

Model

KDT-HD55AC80-P

General

Main Processor

DaVinci High Performance DSP of TI

Operating System

embedded LINUX

Resource

Simultaneous remote monitoring local recording and remote control

User Interface

WEB CMS NVR APP

Camera

Image Sensor

1/2.8” 2.0 Megapixel Progressive Scan Sony Exmor IMX222 CMOS sensor

Effective Pixels

1920(H)×1080(V)

Electronic Shutter

1/5s to 1/50000s

Mini. Illumination

Color:0.2Lux/F1.2 ;B/W:0.01Lux/F1.2;0Lux/F1.2(IR on)

Signal Noise Ratio

>50dB

Day/Night Mode

Auto dual IR-Cut filter

Gain Control

Auto/Manual

White Balance

Auto/Manual

WDR Dynamic Range

DWDR

Lens

2.8mm~12mm/F1.4Manual lens

Max IR Distance

30m

Video

Video Compression

H.264/MJPEG Optional

H.264 Encode Type

H.264 baseline/H.264 Main Profile/H.264 High Profile Optional

Video Bit Rate

Main Stream:200Kbps~12Mbps

Sub Stream:100Kbps~6Mbps

Image Resolution

1080P(1920×1020) / 720P(1280×720) / D1(704×576/704×480)

Encoding Speed

Main Stream: 1080P/720P(1~25fps/30fps)

Extra Stream: D1/CIF:(1~25fps/30fps)

Video Format

PAL/NTSC

Audio

Audio Compression

G.711a/G.711u/RAW_PCM Optional

Audio Bit Rate

G.711a(8kbps)/G.711u(8kbps)/RAW_PCM(16kbps)

Audio Input

1-channel 3.5mm audio interface MIC IN/Line IN

Audio Output

1-channel 3.5mm audio interface (line level600Ω)

Network

Ethernet

RJ-45 (10/100base-T)

Network Protocol

IPv4/IPv6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPoE,SMTP

ONVIF

0NVIF Ver.2.4

Max User Access

10 users

Smart phone

Iphone  Ipad Android

Remote Operation

Monitor Playback System setting File download Log information Maintenance & Upgrade

Auxiliary Interface

Reset Input

One Reset Button(Be effective after continues to hold down for 3 seconds)

Memory Slot

TF Card Max 64GB

RS485

PTZ Control

Alarm Input

1-channel input Normally Open/Normally Close modes adjustable

Alarm Output

1-channel output 120VAC 1A/24VDC 1A

Video Output

1Vp-p Composite Output(75Ω/BNC)

Environmental

Power Supply

DC12V

Power Consumption

<10W

Operating Environment

-40ºC ~ +60ºC Humidity less than95%(Non-condensing)

Dimensions(mm)

154×121.5

Weight(kg)

0.8

Max IR Distance

20m

IP Grade

IP66

PoE

IEEE802.3af
