1.3 Megapixel IP seveillance Security CCTV camera
| | |
| 2.0mp Bullet IP Camera | 2.0mp Dome IP Camera | 2.0 Bullet IP Camera |
| | |
| 1.3mp Dome Network Camera | H.265 2.0MP Network Camera | 3.0MP Network Camera |
Features:
>1/3" 1.3 Megapixel Progressive Scan Aptina CMOS image sensor
>Ti DaVinci Series DSP
>H.264&MJPEG video compression and JPEG image capture
>Max 25/30fps 1.3M (1280×960)/720P(1280×720)
>Dual encoding streams supported
>Lens: 3.6mm Fixed Lens (6mm/8mm optional)
>8pcs 7.5*7.5mm + 1pcs Φ11 IR lights ,Max IR Distance :20m
>True Day/Night ICR
>IP66 all-environments protection
>Support DC12V power supply, PoE
>Built-in Web server, NVR, CMS
Specification:
| Model | KDT-HD19RC72-EP |
| General | |
| Main Processor | Ti DaVinci Series DSP |
| Operating System | embedded LINUX |
| Resource | Simultaneous remote monitoring local recording and remote control |
| User Interface | WEB CMS NVR APP |
| Camera | |
| Image Sensor | 1/3" 1.3Megapixel Progressive Scan Aptina CMOS Sensor |
| Effective Pixels | 1280(H)×960(V) |
| Electronic Shutter | 1/5s to 1/50000s |
| Mini. Illumination | Color:0.1Lux/F1.2; /W:0.005Lux/F1.2; Lux/F1.2(IR on) |
| Signal Noise Ratio | >50dB |
| Day/Night Mode | Auto dual IR-Cut filter |
| Gain Control | Auto/Manual |
| White Balance | Auto/Manual |
| WDR Dynamic Range | DWDR |
| Lens | 3.6mm Fixed Lens (6mm/8mm optional ) |
| Max IR Distance | 20m |
| Video | |
| Video Compression | H.264/MJPEG Optional |
| H.264 Encode Type | H.264 baseline/H.264 Main Profile/H.264 High Profile Optional |
| Video Bit Rate | Main Stream: 200Kbps~8Mbps |
| Sub Stream: 100Kbps~6Mbps | |
| Image Resolution | 1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480) |
| Encoding Speed | Main Stream: 1.3M/720P/D1(1~25fps/30fps) |
| Extra Stream: D1/CIF(1~25fps/30fps) | |
| Video Format | PAL/NTSC |
| Network | |
| Ethernet | RJ-45 (10/100base-T) |
| Network Protocol | Ipv4/Ipv6 RTSP TCP/UDP HTTP DHCP DNS FTP DDNS PPPoE SMTP |
| Common Features | One button Reset Prevent Flicker Dual-stream Heartbeat Password Protect Video cover Motion Alarm |
| ONVIF | ONVIF Ver.2.4 |
| Max User Access | 10 users |
| Smart phone | Iphone Ipad Android |
| Remote Operation | Monitor System setting Log information Maintenance & Upgrade |
| Auxiliary Interface | |
| Reset Input | One Reset Button(Hold on 3 seconds at least) |
| Environmental | |
| Power Supply | DC12V |
| Power Consumption | <6W |
| Working Environment | -40ºC ~ +60ºC Humidity less than95%(Non-condensing) |
| Protection Level | IP66 |
| Dimensions(mm) | 135×135×99 |
| Weight(kg) | 0.65Kg |
| PoE | IEEE802.3af |
CMS&VSS Interface:
Web Interface:
Mobile Phone View:
1. Onvif 2.42, High compatibility, Dahua,Hikivison, Nuuo, Axxon, Milestone, Geovision, Avigilon, Luxriot, See Tec, Aimetis, Genetec
2. GWSECU Strong mental housing; Same housing with different function of different system. H.265/H.264 1.3/2.0/3.0/4.0/5.0 Megapixel IP camera with Motorized lens/ Ultra WDR /low lux/ low stream,HD AHD,CVI,TVI for your choice.
3.GWSECU Perfect structure -heat disspating from bracket, Easy to put SD Card
4. Latest ARRAY LED--- work more longer life.
5.Support Multi-language, P2P and two-dimension Code.
6.User-friendly Web interface and CMS design, convinient for clients to use.
7.High quality control and full OEM Service (put your logo on camera and software, gift box, language.etc)
8.Fast shipping time(500pcs within 15 days).
9. Two year warranty and FREE online technical help with our engineer after sale.
Shenzhen Guowei Security Co., ltd.
Headquarters:
Add.: 6/F, Dong Fang Building 1, No.16 Gaoxin North 6th Road,North High-tech Industrial Park, Nanshan District, Shenzhen, China (518108)
Our Factory
Add.: 4/F, Jinma Building, Shihuan Rd, Shilongzai Community, Shiyan, Baoan District, Shenzhen, China
Zip Code: 518108
Branch:Hongkong Guowei Security co.,limited
Add.: Rm.602,Metro Center I,Lam Hing Street Kowloon Bay.N.T.
We provide 2 years warranty service for all products.
OEM service: Silk-print with brand, IE Browser Login, WEB GUI page, local CMS software with customize brand.
