Sand IP test equipment
ASLI , as a leading sand IP test equipment supplier from china, has more than 25 year’s experience in IP5 dust test chamber manufacture. ASLI boost his own technical team in IP5 dust test chamber R&D, and it also introduces the advance quality control method in IP5 dust test chamber production. Our IP5 dust test chamber series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
IP5 dust test chamber Technical Parameters :
Model |
DT-F1 |
DT-F2 |
DT-F3 |
DT-C1 |
DT-C2 |
Remark |
F for floating dust |
C for cyclone dust |
|||
Concentration of Sand and Dust |
F1: 60000mg/m3
|
F2:3000mg/m3
|
F3:100mg/m3 |
C1: 5000mg/ m3, 5m/s |
C2: 100mg/ m3, 10m/s |
Internal Dimension WxHxD (mm) |
1000x1000x1000 |
1000x1000x1000 |
|||
External Dimension WxHxD (mm) |
1600x1800x1300 |
1650x1850x1450 |
|||
Temperature Range |
RT(25°C±15°C), or lab temperature |
RT(25°C±15°C), or lab temperature |
|||
Humidity Range |
35~90% R.H., or lab humidity |
35~90% R.H., or lab humidity |
|||
Talcum Powder Dosage(Kg/m ²) |
2 ~4 |
||||
Metal Net Mesh Standard Diameter(μm) |
50 |
||||
Diameter Between Metal Wires(μm) |
75 |
||||
Powder Spray & Dust Fall Mode |
1. Dust fall freely: adopt centrifugal fan to blow the sand or dust to the 1/5 of roof, then fall freely. 2. Blow the sand or dust: pressure spray dust from the bottom, multi-steps pressure adjustable |
||||
Test Standard |
Meet JIS, ISO, IEC60529,DIN40050,GB2423 test standard |
||||
Power |
AC 220V(±10%), 1, 3 Lines,50/60HZ ; |
||||
