Bursting strength tester manual and automatic
Bursting strength tester manual and automatic advantages:
1, Measuring tools factory
2, High accuracy feature
3, Reasonable price
4, Fast delivery
Bursting strength tester manual and automatic technical parameters:
Model |
AS-BS-100 |
Sensing Method |
Pressure convertor |
Display Mode |
LED display mode |
Volume(option)-high Pressure Mode |
0~100kg/cm2(accuracy 0.1kg/cm2) |
Volume(option)-low-pressure Mode |
0~16kg/cm2 (accuracy 0.02kg/cm2)
|
Oil-pressure Speed (ml/min) |
170±10 |
Radius of Rim lock-upper Ring(mm) |
High pressure mode Φ31.5, |
Radius of Rim Lock-lower Ring (mm) |
High pressure mode Φ31.5, |
Oil Pressure Gauge |
0~25kg/ cm2 |
Motor |
AC220V |
Volume WxHxD (mm) |
530x570x235 |
Weight (Kg) |
65 |
Power |
AC220V 1&3 lines |
Power Consume |
200W |
Optional Accessories |
Micro-printer |
Bursting strength tester manual and automatic application:
Bursting strength tester manual and automatic is used to test the strength and performance of materials like
paper, paperboards, corrugated boards and boxes, solidfibre boards, filter cloth, industrial fabrics,
leather, rexine, etc.
Bursting strength tester manual and automatic features:
1. Digital display pressure
2. Matched motor gives constant pumping rate for better performance, eliminating manual error.
3. Three spare rubber diaphragms and one bottle of hydraulic fluid supplied with machine.
MACHINE VIEW
Our Services
Warranty: one year free warranty for whole set machine,lifelong time maintainance.
After-sale service: feedback within 8 hours after get the call or email.
Service:OEM service,Design service,Buyer lable service.
Package: Standard export wooden case, plywood case or according to customer's requirement.
ASLi main products: Environmental chambers, temperature (humidity) chamber, PCT /Hast chamber (Highly accelerated stress test chamber),ESS chamber, Walk in stability chamber,Vacuum oven,Altitude chamber,vibration test system, mechanical shock tester,environmental combined vibration chamber,etc
