IPX3,IPX4 Water Absorption Tester
Water Spray Chamber /Application:
Rain Spray Test Machine is used to test the shell’s waterproof effect of electronics, automobile and communication, using rainfall simulation to test the product’s waterproof performance and assess the product’s waterproof performance’s loss classification.
Water Resistance Test Chamber /Feature:
1. Water pressure and flow rate adjustable.
2. Unique sprinkler can stably control the rain quantity and pressure.
3. This equipment (Model RT-1000B) can make the test products’ temperature rising from RT to 85°C
4. Interior workspace material is steel plates, exterior is #304 stainless steel.
Rain Test Chamber /Technical parameters:
1.Model:RT-1000A:RT-1000B
2.Test Standard:JIS, ISO, IEC60529, DIN40050, GB2423, GB4208 standard
3.Internal Dimension WxHxD (mm):1000x1000x1000
4.External Dimension WxHxD (mm):1600x1900x1400
5.JIS Test: Flow 1.8L/Min~3.9L/Min,pressure 0.1kgf/cm2~0.3 kgf/cm2
Flow 24.5L/Min~39.2L/Min,Pressure 1kgf/cm2~3 kgf/cm2
6.Drop Test: 1~1.5mm/Min Adjustable ;IPx1 IPx2 drop speed1~1.5mm/Min adjustable; 3~3.5mm/Min Adjustable drop speed 3~3.5mm/Min adjustable
7.Rain of Pipe-Swing Test: IPx3 IPx4 swing pipe RT~±80°C;Flow 0.07L/min per Nozzle
8.Water Spray Test:IPx3 IPx4 jet:2.5m~3m;flow 12.5L/min ~100L/Min
9. High Pressure Jet Test:80Kgf~100Kgf;IPx9K pressure of jet:80Kgf~100Kgf Flow 14~16L/Min
10.Rotating Speed of Rotating-Plate:4~20 RPM adjustable
