Computer Servo Control Tensile Testing Machine Application:
Servo Tensile Testing Machine is an electrically operated machine that is used for testing tensile strength and elongation of materials like plywood, wires, cables, conductors, ferrous and non-ferrous materials.
Computer Servo Control Tensile Testing Machine Features:
1. Force value and deformation can display at the same time.
2. Drive by servo motor, stand-alone can sent testing speed directly.
3. Press Start button the machine will testing automatic after setting.
4. After finishing testing, it can self-return.
5. Fast disassembly joint, can use different kinds grips.
6. Single button testing function, easy operation
7. Direct-connected to printer, print out report.
Computer Servo Control Tensile Test Machine Technical parameters:
Model |
AS-PC- Volume |
Capacity (Kg) |
50,100,200,500,1000,2000,5000,10000,20000 |
Load Accuracy |
0.5% |
Load Resolution |
1/100,000 |
Valid Width (mm) |
400 |
Max. Route (mm) |
1000(not including clamp) |
Test Speed (mm/Min.) |
0.1~500(1000) |
Speed Accuracy |
±0.5% |
Motor |
AC servo motor |
Volume WxHxD (mm) |
1750x3310x1220 |
Weight (Kg) |
300 |
Power |
AC220V 3 lines AC380V 5 lines |
