Help CenterAS-8818 Automatic Insersion Force Test Instrument
Related Products
-
Professional Paper Tape Abrasion Testing MachineUS$ 2,000 - 10,000MOQ: 1 Set -
Falling Ball Impact Testing MachineUS$ 1,500 - 5,000MOQ: 1 Set
-
Desktop Tensile Testing EquipmentUS$ 1,500 - 5,000MOQ: 1 Set
-
ASLi Bursting Strength TesterUS$ 2,000 - 10,000MOQ: 1 Set
-
Automatic Insersion Force Testing MachineUS$ 5,000 - 25,000MOQ: 1 Set
Automatic Insersion Force Test Instrument /Automaitc Insersion Force Testing Machine /
Automatic Inserting & Extracting Test machine
Automatic Insersion Force Test Instrument Technical Parameters
Max. Load (Kg) |
1, 2, 5, 10, 20, 50 (optional) |
Analytic Accuracy(g) |
0.01 or 1 |
Max. Test Height(mm) |
150 |
Min. Distance of Fine Tuning (mm) |
0.01 |
Test Speed Range(mm/min) |
0~200 |
X.Y Axis Moving Range (mm) |
0~75 |
Automatic aim the center device |
|
Force Transport Mechanical Structure |
Ball screw |
Drive Motor |
Servo motor |
External Dimension WxHxD (mm) |
360x260x940 |
Weight(Kg) |
67 |
Power |
AC220V 1& 3 lines |
Automatic Insersion Force Test Instrument Features :
1. Adopt windows displayer, easy to operate, automatic memory (torque & angle curve, torque life time curve, test report),
also can memorize all the test conditions.
2. Adopt high precision load cell and droved by servo motor, can get accurate Inserting & extracting force testing data.
Automatic Insersion Force Test Instrument Applications :
Automatic insersion force testing machine is applied for the inserting and extracting test of all kinds of connectors.
Equiped with automatic center system and special connecting grips to make sure to get accurate testing result.
Automatic Insersion Force Test Instrument Pictures :
...
