Shock and Vibration Testing Chamber

Name: Shock and Vibration Testing Chamber
Brand: ASLi
SKU: 110166775

US$ 1,500 - 2,200 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ASLi

Model Number:

AS Seires

Dongguan ASLi Test Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ANY CHINESE MAIN PORT

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ASLi

Model Number AS Seires

Power Other, Electronic, AC220V or according to the equipment specification

Usage Vibration Testing Machine

Shock and vibration testing chamber application:

Shock and vibration testing chamber is for qualification tests to validate transport holdings of a product , as well as the packaging.

Shock and vibration testing chamber features:

1. Unique design, easy to use

2. Low noise, with buffering function

3. Frame is powder coating

4. Working table is stainless steel

5.Aluminium alloyrail track

Shock and vibration testing chamber technical parameters:

Model	AS-100	AS-200	AS-300	AS-600	AS-1000
Load (Kg)	100	200	300	600	1000
Effective Area WxD (mm)	1200×1000	1200×1000	1200×1300	1300×1400	1500×1500
Weight (Kg)	200	250	350	450	600
Exterior Dimension WxHxD (mm)	1300×650×1300	1300×650×1300	1300×650×1400	1400×750×1500	1600×850×1600
Rotating Speed (RPM)	150 to 300
Amplitude	25.4mm(1inch), (Accord ASTM.IEC transport standard)
Time Setting (Approx.)	0 to 999hours
Mode of Vibration	Reciprocating type
Power	AC220V or according to the equipment specification
