IP VANDAL-PROOF DOME CAMERA With Varifocal Lens 4~9 mm

IP VANDAL-PROOF DOME CAMERA With Varifocal Lens 4~9 mm thumbnail-1
IP VANDAL-PROOF DOME CAMERA With Varifocal Lens 4~9 mm photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
K&D
Model Number:
KD-DD50XD48
Contact Supplier Request Quote Chat Now
Shenzhen Guowei Security Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name K&D
Model Number KD-DD50XD48
Type IP Camera
Style Dome Camera
Sensor CCD
Technology Infrared
Special Features Vandal-proof

Specifications

IP VANDAL-PROOF DOME CAMERA
1/3"SONY SUPER HAD II CCD
Video Resolution: D1, HD1, CIF, QIF
build in 4~9 mm lens

IP VANDAL-PROOF DOME CAMERA



1/3"SONY SUPER HAD II CCD

Minimum illumination: 0.1Lux (color)@F1.2

Video Resolution: D1, HD1, CIF, QIF

 Build in 4-9mm varifocal lens, Vandal-proof



Features:

 -The video is compressed by MJPEG. There are VGA/QVGA/QQVGA three video resolutions optional. User can change some parameters according to their demands to satisfy his own visual prefer.
 -With built-in Microphone, it enables user to monitor the sound on the site. User can also connect this equipment to the speaker, and it supports two-way intercom function.
 -It was equipped with pan/tilt function, horizontally 270°and vertically 120°. Its outlook is smart, easy and convenient to install in many sites.
 -It adopts the TCP/IP network protocols and has inner web server. Users can browse video through IE and other browsers. Data is transferred through one port; it is easy for user to do the network setting.
 -Support 802.11b/g/n protocol, can build up wireless monitoring.
 -Supports UPNP, port forwarding automatically on the router.
 -Motion detection and alarm pin can be connected to external sensors to detect environmental situation.
 -Alarming record can be stored by email, FTP server. External alarm can be open when detecting unusuality. It also sends alarm info to the alarm server.
 -Infrared LED for night vision covers 5m area, to realize 24 hours monitoring.
 -Support mobile phone to view
 -Support three level of user authority.
 -Support upgrading online.
 -Manufacture attached a label at the bottom of each IP Camera, it include Device ID, DDNS. When IP Camera is connected to the internet, this URL can be used to visit the device.
 -Manufacture provides free software, support Multi-view, Long time recording, video replay etc.



KD-DD50XD48

480TVL, 0.3Lux (color)@F1.2 Wired

KD-DD50XD60

600TVL, 0.1Lux (color)@F1.2 Wired

Image sensor

1/3" Sony Super HAD II CCD

Video compression

H.264 Main Profile @Level 3/MJPEG

Video Definition

PAL:176X144(QCIF),352*288(CIF),704*288(2CIF),704*576(D1)

NTSC:176X120(QCIF),352*240(CIF),704*240(2CIF),704*480(D1)

Video Frame Rate

PAL: 1-25fps NTSC:1-30fps

Video Bit rate

32Kbps~16Mbps

Audio Compression

G.726 , 32K bits

Audio Output

1channel, linear output,

Audio Input

1 channel external MIC interface( internal sound pick-up)

Title OSD

Supports channel name, date, and video stream information overlay; OSD location is adjustable

SD Card Interface

Support Video and Snapshots stored ,SD2.0 SDHC standard and maximum capacity:32GB

Network Interface

Self-adaption 10/100Mbps RJ45 port

Network protocol

TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP

Serial port

1 channel RS485

Alarm Input

1channel  input, NO/NC modes adjustable

Alarm Output

1 channel  output, 120VAC 1A/24VDC 1A

E-mail Alarm

Support

FTP Protocol

Support

RTSP Protocol

Support

Mobile Monitor

Supports smart mobile monitor that is based on  Windows Mobile, Symbian and  iPhone platforms

Working Temperature

-10°C - +55°C

Working Humidity

0% - 90%

Power Input

DC12V/1.0A

Power Consumption

8W (MAX)

Dimension

113mm(H)*141mm(Φ)

Net weight

0.6kg

Package:

8pcs/carton, 12.4kg/carton, 580x430x340mm





Warranty:

Two year to provide fixing, and one month to provide changing new. The warranty is based on the broken not caused by human being.



After-sale service

 Products purchased through K—D, under warranty may be for

 replacement or repair by following steps:

 1.  Contact K—D customers’ service.

 2. You must provide the problems (including original model, order number, order date and the unique number on the IP camera).

 3.  You must be sure that the mark clears in the IP camera and the unique number in the package.



IP VANDAL-PROOF DOME CAMERA with varifocal lens 4~9 mm
