Third-Generation LED ARRAY Dome Camera

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

KD-SD58AT42

Shenzhen Guowei Security Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen china

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name KD

Model Number KD-SD58AT42

Style Dome Camera

Sensor CCD

Technology Other, Vandal-proof

Special Features Waterproof / Weatherproof

Type Other, Video Camera

Specifications

1:Scrape-proof design
2:1/3" SONY Super HAD II CCD
3:Max horizontal resolution 650TVL
4:IR distance 30m

Model	KD-SD58AT42	KD-SD58AT65	KD-SD58AT60-WDR
Image Sensor	1/3" SONY Supper HAD II CCD
System	PAL/NTSC
Horizontal Resolution	420TVL	650TVL	600TVL
Minimum Illumination	Color:0.5Lux /F1.2	PAL:976(H)x582(V) NTSC:976(H)x494(V)	Color:0.003(0.6)LUX (Sens-up OFF) B/W:0.0001(0.1)LUX (Sens-up OFF)
Effective Pixels	PAL:500(H)×582(V) NTSC:512(H)×492(V)	PAL:976(H)x582(V) NTSC:976(H)x494(V)	PAL:795(H)x596(V) NTSC:811(H)x508(V)
S/N Ratio	More than 48dB	52dB(Min)/60dB(Max)(AGC ON/OFF)	52dB(AGC OFF)
DNR	N/A	Low/Middle/High/Off	3D-DNR Off/On(1~63 level adjustable)
AGC	Auto	Off/Low/Middle/High	Low/Middle/High/Off selectable
White Balance	Auto	Atw/Manual/Push	ATW/AWC/Manual/Outdoor(1,800°K~10,500°K)Indoor(4,500°K~8,500°K)
Mirror function	N/A	Horizontal Mirror	Horizontal Mirror;Vertical Mirror
Privacy zone	N/A	On/off (4 areas)	On/Off(8 areas )
Motion Detect	N/A	On/off (4 areas)	On/Off(8 areas, Alarm output)
Day &Night	AUTO(option)	Color, B/W, Auto(level adjust)	Color/ Black & White/Auto/Exit
BLC	on/off	Off/Low/Mid/High	WDR/BLC/OFF selectable
Menu Control	N/A	YES
D-WDR	N/A	ON/OFF
Electronic Shutter	1/50(60)~1/100,000 sec	1/50(1/60)~1/120,000 sec
Digital Zoom	N/A		×8.3(adjustment vertical and horizontal angle )
Communication protocol	N/A		Pelco D / Pelco P (Menu using the RS485 control )
Video Output	1.0Vp-p/75Ω
Sensing Area	4.9mm*3.7mm
Sync System	Internal
Gamma	0.45
Waterproof	IP67
Infrared light	Use highlight Array infrared light
IR Distance	30m
Lens	4~9mm varifocal lens
Power Supply	DC12V
Operation Temp.	-10°C~50°C
