960P CMOS Indoor/Outdoor HD CVI 16X Mini Speed Dome Camera Dahua CVI PTZ Camera

Name: 960P CMOS Indoor/Outdoor HD CVI 16X Mini Speed Dome Camera Dahua CVI PTZ Camera
Brand: Dahua
Price: USD $120 - 180 / Piece

FOB Price

USD $120 - $180 / Piece

1 Piece(Min.Order)

Supply Ability 1500 Piece / Pieces per Month
Payment Terms:T/T L/C D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Zhejiang, China	Brand Name:	Dahua	Model Number:	SD42112I-HC
Type:	Analog Camera	Style:	Dome Camera	Sensor:	CMOS
Technology:	Pan / Tilt / Zoom	Special Features:	Waterproof / Weatherproof

Product Description

960P CMOS Indoor/Outdoor HD CVI 16X Mini Speed Dome Camera Dahua CVI PTZ Camera

Product Description

Features

>Powerful 12x optical zoom
>25/30/50/60fps @720P
>DWDR, Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
>Max 300°/s pan speed, 360° continuous pan rotation
>Control over coaxial cable, long distance real-time transmission
>HD and SD switchable
>Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
>Built-in 2/1 alarm in/out
>Support intelligent 3D positioning with DH-SD protocol
>IP66, IK10(optional), OSD

Technical Info:

Model	DH-SD42112I-HC
Camera
Image Sensor	1/3" Exmor CMOS
Effective Pixels	1280(H) x 960(V)
Horizontal Resolution	≥700TVL
Scanning System	Progressive
Electronic Shutter Speed	1/1s ~1/30,000s
Min. Illumination	Color: 0.05 Lux/F1.6, B/W: 0.005Lux/F1.6
S/N Ratio	More than 55dB
Resolution	25/30/50/60fps@720P
Video Output	1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (Can switch)
Camera Features
Day/Night	Auto(ICR) / Color / B/W
Backlight Compensation	BLC / HLC / DWDR (Digital WDR)
White Balance	Auto, ATW, Indoor, Outdoor, Manual
Gain Control	Auto / Manual
Noise Reduction	2D / 3D
Privacy Masking	Up to 24 areas
Digital Zoom	16x
Lens
Focal Length	5.1 mm~61.2mm (12x Optical zoom)
Max Aperture	F1.6~ F3.0
Focus Control	Auto / Manual
FOV-H	H: 51.3° ~ 4.6°
Close Focus Distance	100mm~1000mm
PTZ
Pan/Tilt Range	Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180°
Manual Control Speed	Pan: 0.1° ~ 300°/s; Tilt: 0.1° ~120°/s
Preset Speed	Pan: 300°/s; Tilt:200°/s
Preset	80(DH-SD) , 255(Pelco-P/D)
PTZ Mode	5 Pattern, 8 Tour, 5 Auto Scan, Auto Pan
Speed Setup	Human-oriented focal length/ speed adaptation
Power up Action	Auto restore to previous PTZ and lens status after power failure
Idle Motion	Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
Protocol	DH-SD, Peclo-P/D (Auto recognition)
Audio
Interface	1 channel In
Auxiliary Interface
RS485	1
Alarm	2/1 channel In/Out
General
Power Supply	AC24V/1.5A (±10%)
Power Consumption	10W
Working Environment	-10ºC ~ 60ºC / Less than 90% RH
Ingress Protection	IP66
Vandal Resistance	IK10(optional)
Dimensions	Φ170mm×155mm
Weight	1.8Kg

Certificates:

Quality Assurance

Our Services

Shenzhen Guowei Security Co.,Ltd is specialized in research and innovation of surveillance video technology. Providing security surveillance equipments, solutions and services worldwide.

Established in 2006, Guowei mainly researched and manufactured KD series analog cameras at earlier stage. The company has long term technical cooperation with some famous enterprises, and with years research and development, launched KDT series network high definition cameras and NVR with independent property rights in 2012. Guowei is a member of ONVIF organization with products completely compatible with ONVIF standard protocol. And the company products has perfect matching with internal mainstream storage device manufacturers (Dahua NVR, Hikvision NVR) and external platform (eg.Milestone, Axxon Digifort, NUU0, Luxriot and Geovision).

To guarantee stable performance, Guowei has strict control on design, raw material and processing of its products. The company adopts remote online technical service. And all the products have been successfully certificated by CE, FCC, ROHS.

Guowei takes "value creation, win-win cooperation" as management principle and "specialty, speed, sincerity" as service philosophy. Guowei contributes to the peaceful world.

Any questions or anything we can help you kindly please let us know.

Shenzhen GuoWei (K&D) Security Co .,Ltd

CCTV Security manufacturer since 2001
