Unsaturated Pressurized Humidity Test Systems
ASLI , as a leading unsaturated pressurized humidity test systems supplier from China, has more than 25 year’s experience in unsaturated pressurized humidity test systems manufacture. ASLI boost his own technical team in unsaturated pressurized humidity test systems R&D, and it also introduces the advance quality control method in unsaturated pressurized humidity test systems production. Our unsaturated pressurized humidity test systems series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
Unsaturated Pressurized Humidity Test Systems Features:
1. Asli brand unsaturated pressurized humidity test systems has automatic adding water function, and automatic filling water upon the water short storage while testing.
2. Asli brand unsaturated pressurized humidity test systems with automatic operation to test process finished, easy to use.
3.Asli brand unsaturated pressurized humidity test systems temperature control: LED digital temperature controller can make accurate testing of temperature setting, control and display.
4. Asli brand unsaturated pressurized humidity test systems has LED digital timer, when the inner box's temperature reached the setting value, then start to time to ensure the test complete.
5.Asli brand unsaturated pressurized humidity test systems with accurate pressure: temperature chart always shows the inner box's pressure and relative humidity.
6.Asli brand unsaturated pressurized humidity test systems with water device is automatically discharge not saturated steam in order to achieve the best steam quality.
7.Asli brand unsaturated pressurized humidity test systems has a integrated silica gel door gasket, air tightness is very good, and long operation life.
8.Asli brand unsaturated pressurized humidity test systems the inner box is mirror-polished , graceful and non-pollution
Unsaturated Pressurized Humidity Test Systems Safety device:
1. Safety device for the pot: If the inner box is not closed , the machine can not start
2. Safety Valve: when the inner box's pressure higher than the machine's undertake value, it will self-relieve.
3. Double overheat protection device: When inner box's temperature is too high, it will alarm, and Automatic cut off the heating power.
4. Cover protection: The inner box's cover is made of aluminum alloy, can protect the worker from scald
Unsaturated Pressurized Humidity Test Systems Technical Parameters:
Model |
HAST - 55 |
||||
Internal Dimension:Φ×D (mm) |
550×650 |
||||
|
External Dimension Φ×D (mm) |
1150×1650×1200 |
||||
Steam Temperature Range |
Steam Temperature Range: 100°C~135°C, (143°C is optional) |
||||
Relative Pressure/ |
Relative pressure: display values indicated on the pressure gauge pressure gauge (The actual value in the inner box) |
||||
Steam Humidity |
70~100%R.H. steam humidity adjustable |
||||
Steam Pressure(Absolute Pressure) |
101.3Kpa +0.0Kg/cm2~2.0Kg/cm2 ; (3.0Kg/cm2 is special standard) |
||||
Recursive Device |
Steam in forced-circulation |
||||
|
Safety Protective Devise |
Water short storage protect, over pressure protect.(have automatically/manual water replenishing, automatically discharge pressure function ) |
||||
Accessories |
Two layers stainless steel plate |
||||
Equipment Capacity(L) |
155 |
||||
Powder |
AC220V, 1Φ 3 Lines ,50/60HZ; AC380V ,3 Φ 5 Lines,50/60HZ |
||||
Unsaturated Pressurized Humidity Test Systems Pictures
...
