Help CenterNitrogen High Temperature Oven
Related Products
Nitrogen High Temperature Oven application:
Nitrogen high Temperature Oven is used in the electronics industry, electrical, communications, hardware, chemical, sports equipment, printing, pharmaceuticals, footwear, automotive spare parts and other industrial for baking, drying, preheating and tempering, aging purposes.
Nitrogen High Temperature Oven features:
1. Microprocessor temperature controller
2. Rapid sterilization time
3. Forced air convection
4. Auto stop when temperature over limit
5. Air inlet adjustment & timing control, the device is equipped with imported nitrogen flow meter, and with a quick plug nitrogen filling interface, convenient nitrogen filling and control the nitrogen flow.
Nitrogen High Temperature Oven technical parameters:
Model |
RHD - 45 |
RHD - 60 |
RHD - 90 |
RHD - 120 |
|
Inner Dimension W×H×D(mm ) |
450×400×400 |
500×600×500 |
600×900×500 |
800×1200×700 |
|
Outer Dimension W×H×D (mm ) |
650×900×550 |
700×1200×650 |
850× 1600×700 |
1200× 1680×900 |
|
Interior and Exterior Material |
Interiror material is SUS 304# stainless steel, Exterior material is stainless steel or SEE cold-rolled steel with paint coated. |
|||
Temperature Range |
RT to 200°C, (300°C to 500°C is optional) |
|||
|
Indication Resolution / Distribution Uniformity of Temperature |
0.1°C/ ±2.0°C;(When temperature is 100°C) |
|||
|
Control Accuracy of Temperature |
±0.5°C; |
|||
|
Temperature Rising Velocity |
Temperature rising velocity: RT to 200°C; Approx. 35mins |
|||
Control Method |
Micro PID+SSR+Timer |
|||
Nitrogen Device |
Nitrogen in-out interface and pressure relief valve on the back of equipment, |
|||
Storage Shelf |
Two layers |
|||
Viewing Window |
When temperature is RT to 200°C ,with viewing widow When temperature is 200°C to 500°C ,without viewing widow |
|||
Power |
AC 220V 50/60HZ ; AC 380 V 50/60HZ |
|||
