Security & Surveillance HD Network Control Keyboard

Security & Surveillance HD Network Control Keyboard thumbnail-1
Security & Surveillance HD Network Control Keyboard photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
K&D
Model Number:
KDW-DN508HM
Contact Supplier Request Quote Chat Now
Shenzhen Guowei Security Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name K&D
Model Number KDW-DN508HM

Specifications

Support full HD 1080p live view; Support HDMI & VGA sync output
Support external Wi-Fi (Optional)
Auxiliary Functions, OSD

Security & Surveillance HD Network Control Keyboard



>Programmable 4D-switch desktop HD Network keyboard

> Keyboard to Control:
—Standalone DVR
—(Network) High Speed Dome
—High Speed Dome
—Central Management Platform
—Network Video Server
> RS232, RS485 & Network Connections
> Four Dimensional Joystick Control of PTZ Functions
> Support full HD 1080p live view; Support HDMI & VGA sync output
> Support snapshot and recording to U-disk
> Support Video-Wall display
> Support external Wi-Fi (Optional)
> Support bidirectional talk
> Preset Position, Auto Scan, Auto Pan, Auto Tour & Pattern Control
> Auxiliary Functions, OSD and operation guides.





Model

KDW-DN508HM

System

Main Processor

Industrial embedded microprocessor

Operation System

Embedded LINUX

Audio

Compression

G.711A

Output

1ch output

Bidirectional Talk

1ch input and 1ch output

Display

Display split

1/4/8/9/16

Resolution

1080P/720P/D1/HD1/BCIF/CIF/QCIF

Screen

10.2" touch screen LCD (touch pen)

General

Keyboard Panel

Electromechanical

Joystick

4-axis(zoom, focus, iris)

Control

Output
Control

Support video-wall display
HDMI/VGA output

Control Mode

Direct Mode

Interface: 1 RS232/ 2 RS485
DVR Protocol: DH1/DH2
Dome Protocol:
DH-SD/PELCO-D/PELCO-P/PELCO-D1/PELCO-P1 and etc.

Network Mode

Interface: RJ45(1 RJ-45 port (10/100/1000M)) / Wi-Fi
DVR/Network Dome:
IP Address/Port/Protocol

Max Remote Users

20 (each can manage up to 256 unit devices)

USB Interface

2 ports, for mouse control & backup

Environmental

Power Supply

DC12V

Power Consumption

5W

Working Temperature

-10°C ~+55°C

Working Humidity

10%~90%

Atmosphere Pressure

86kpa~106kpa

Dimension

480mmx240mmx87mm (W×D×H) (height: exclude joystick)

Weight

4.5KG
